Product Details
| Place of Origin | Guangdong, China | Brand Name | Joney | |
| Model Number | JYA-1306EM |
Product Description
1m middle range rfid reader proximity 125Khz reader with wiegand26/34 interface
Details:
EM format proximity RFID tag 125KHZ reader formiddle range 125 KHz RFID tag and
card reading applications. Suited for home or office and building security, personnel
access control, manufacturing and control systems.
Mainly used for parking, elevator, logistics industry,etc.
Notification:
The Reading range is a complex parameter,So called "1M range",only means the unit
works with the special long range card,that is a 2mm thickness credit size card.
Normally,the unit can also work with normal EM cards,normal 2mm thickness card
can reach 60cm range,0.8mm card can reach 40cm range.
Features : card access control, card access control, card access control
Decode time: <0.2s
Communication: Weigand 26/34/Poris RS485
Card type: EM card,EM compatible card (Can't support HID, Cobra, APCiK etc)
Frequency: 125kHz
Induction Distance: Common Card up to 30-40cm / Long range proximity card up to 70-100cm
Power supply: DC 12V
Data transfer range: ≤80mA
Currency: <200MA
Working Temperature: 0~70°C
Working Humidity: Less than 80%
Dimension (LxWxH mm): 235*235*35
Material: Plastic casing & epoxy saturated
Specification : card access control, card access
Model | JYA-1306EM |
Size | 260*260*35(mm) |
Color | Dark Grey |
Voltage | DC12V |
Current | ≤100mA |
Respond to speed | <0.2 s |
Ambient Temperature | -25°C~75°C |
Reading Range | 70~100CM |
Output Format | Wiegand 26/34,RS485/232 |
Card Type | EM-ID Middle distance card |
Comunication Distance | WG≤100M,RS485≤1200M |
