Home > Products > Power cable > Best quality 0.6/1KV 4*240+1*120mm2 copper conductor power cable XLPE/PVC cable flat wire power cable
Best quality 0.6/1KV 4*240+1*120mm2 copper conductor power cable XLPE/PVC cable flat wire power cable
- 500000 Meter / Meters per Month
- Shanghai Tianjin Qingdao Guangzhou
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Aluminum Conductor PVC Insulated PVC Sheathed Power Cable
-
PVC insulated power cable of rated voltage up to and including 3.6 / 6KV
-
Low Voltage Type and Copper / aluminium Conductor Material pvc insulation wire
-
PVC Insulation Material and Low Voltage Type armoured cable with rated voltage 3.6 / 6KV
-
Copper Conductor PVC Insulated PVC Sheathed Power Cable
-
0.6/1kv Copper Conductor PVC Insulated Power cable /95mm2,120mm2.240mm2,185mm2,150mm2,300mm2
Product Details
Place of Origin | Henan, China | Brand Name | BEI HOU | |
Model Number | YJV YJV22 YJV32 YJLV YJLV22 YJLV32 | Insulation Material | XLPE | |
Type | Low Voltage | Application | Construction | |
Conductor Material | Other, copper or aluminum | Jacket | PVC |
Product Description
Best quality 0.6/1KV 4*240+1*120mm2 copper conductor power cable XLPE/PVC cable flat wire power cable
Lower voltage xlpe insulated power cable:
1 Product Standard
This product is manufactured according to GB/T12706.1, equivalent to IEC60502.1. Or BS, DIN, ICEA standard as customer request.
2 Application
The product is suitable for power transmission and distribution lines with rated power frequency voltage up to and including 0.6/1KV.
Operating Performance
1). Rated power frequency voltage Uo/U: 0.6/1KV.
2). Max. Permissible continuous operating temperature of conductor: 90℃
3). Max. Short-circuit temperature of the conductor shall not exceed: (5S maximum duration) 250℃
4). The ambient temperature under installation should not below 0℃
5). The bending radius of a cable should not be less than 15 times of the cable diameter.
6). The test voltage (A.C.): 3.5kV/5min.
7). The flame-retardant properties of cable comply with grade A, B, C of GB/T19666-2005 or IEC60332.
3 Construction:
Conductor: Solid or stranded copper,aluminum
Insulation: Cross-linked polyethylene( XLPE or PVC)
Circuit: Identification: The insulation shall be red, black
Filler: Polypropylene lament with lapped binding tape
Inner Sheath: Polyvinyl chloride (Black)
Armor: Galvanized steel wire
Core-covering: Binding tape
Outer Sheath: Polyvinyl chloride (Black)
Package: Wooden Drum Package or Iron-wooden drum
1).Wrapped in rolls/coils/rings with plastic film for small diameter cables such as building wires.
2).Treated wooden/steel-wooden drums for big diameter cables.
3).Cables are normally supplied in lengths of 100 meters,500 meters and 1000 meters according to cable size.Other lengths could be supplied if agreements are reached by both side.
Packaging: In rolls/coils, wooden drums, steel drums or steel-wooden drums.
Shipping:
1. Sample will be mailed by DHL, UPS, FEDEX, TNT, EMS etc for your selection (Freight Charge normally will be on buyer’s account).
2. Large quantity will be shipped by sea
1.We are factory and raw materials are served by our company.
2.OEM and ODM are available based on official legal authorization.
3.Strict quality control system.
4. Faster lead time than our competitors.
5. Excellent quality with reasonable price.
6. Strong technical support.
7. Providing solutions for your particular requirements.
8. Free samples are available with economic express fees.
We always adhere to the principle of "quality first, customer satisfaction first". If you have any questions, please feel free to contact us through e-mail, phone, and trade message or other ways.
Established: 1996.
Factory area: 60,000 square meters, and 40,000 square meters for building area.
Fixed assets: USD 200 million.
No.of stuff : over 1,000.
Annual output: 100,000 tons.
Certificates: IEC, ISO 9001, ISO 14001, CCC, BV, JIS, UL, BS, OHSAS 18001, TUV, CE
CB and so on.
Workshops: rubber cable workshops, conductor workshop, XLPE cable workshop, electric cable workshop, special cable workshop, and workshops for telephone wire , TV lines and parvicostellae.
Zhengzhou Yuanda Cable Co. Ltd. located in the middle of China, can deliver qualified cables and wires in very short lead time for each clients.
Yuanda cable products:
1. XLPE Power Cables
2. Building Wires & PVC Cables
3.Rubber &Welding Cables
4.Flame- Retardant/LSZH Cables
5.Aerial Bundled Cable (ABC)
6. Control Cables
7. Aerial Cables
8.CAT5E,CAT6 Network Cable
10.Rubber Cables
11.Plastic Insulated Cables
12. Telephone and TV lines
13. Sockets and Switches
14. Cables and Wires customized
If you have any demands or requirements, please do not hesitate to contact us. Our company will provide best services for you.
Q1: Are you a factory or trading company?
A: Zhengzhou Yuanda Cable Co. Ltd (Headquarter) is a large manufacture in the middle of China with 1, 000 staff.
Q2: Where is your company? How can I visit there?
A: Our Company is located in Room 2304, Building 1, No. 157 Fuyuan Road, Jinshui District, Zhengzhou, Henan, China. Visitors can come to our company by train to Zhengzhou station or by plane to Zhengzhou Airport.
Q3:How can I get samples?
A: Free Samples will be sent to customers by economic international express if available, Freight Charge will be normally on buyer’s account.
Q4:How does your factory do regarding quality control?
A: Zhengzhou Yuanda Cable Co., Ltd. has passed ISO 9001 and ISO 14001, CCC certificates. Each products must be went through professional test. We promise to provide qualified cables.
Q5: Which payment terms do you accept?
A: The payment term varies with different price and total value of each contract.
Common terms are as follows:
a.100% TT advance for small amount orders.
b. T/T 30% deposit, and balance payment negotiable accordingly.
Other payment terms also can be available by both sides agreement.
Q6: Have you ever exported cables to other countries?
A: Yuanda Cables have been supplied to many countries especially in Middle East,Middle Asia,South America,Southeast Asia countries and regions etc.
Q7: What is your MOQ?
A: MOQ varies as per the cable type.Normally 500 meters for big diameter cables. Please feel free to contact us directly for detail information if you have any specific requirements.
