High Quality Sash Mortise Lock
Negotiable
/ Piece
40 Pieces(Min. Order)
- T/T Credit Card PayPal
You May Like
-
ICSA Mortise Lock at Special Price With Five Year Warranty - Made in Italy
-
ICSA Double Cylinder at Special Price With Five Year Warranty - Made in Italy
-
ICSA Knob Cylinder at Special Price With Five Year Warranty - Made in Italy
-
No Smoking Stainless Steel Sign Board
-
Bathroom Door Stainless Steel Sign Board
-
UL Listed Power Transfer Fire Door Accessories
Product Details
| Place of Origin | China | Brand Name | Hager | |
| Model Number | 3800U - 60S |
Product Description
Specifications
Certifications: EN 12209: 2003EN 1634-1: 2000 (4-Hour Fire Rated)
CE Classification 3X510F3BC20
Backset: • 55 mm (2-3/16 in) - 3800U-55S
• 60 mm (2-11/32 in) - 3800U-60S
Forend Length: 137.5 mm (5-13/32 in)
Forend Width: 24 mm (31/32 in)
Deadbolt Length: 35 mm (1-3/8 in)
Strike Length: 98 mm (3-7/8 in)
Strike Width: 24 mm (31/32 in)
Material: Steel
Finish: US32D
Includes: Mortise lock, strike plate, fixing screws, and dust box
Fasteners: Four (4) #6 x 25 mm (1 in) FPHWS
Warranty: Three-year
Notes: • Cylinders and levers sold separately
• Field reversible; non-handed
• 3 mm (1/8 in) forend round corners available upon request
