Heating Element With 3M Adhesive Low Voltage
- Shanghai
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Huilong | |
| Model Number | HL |
Product Description
Heating element with 3M adhesive low voltage
Featurs:
The silicone rubber heaters have advantage of thinness, lightness and flexibility.
It can improve heat transfer, accelerate warming and decrease power under the process of operation. Fiberglass reinforced silicone rubber stabilizes the dimension of heaters.
We can produce the silicone rubber heater for the low volts and high volts.
The maxium wattage can be made for 1.5w/square cm.
The heaters can be made for any size and any shapes.
It is easy to install because of we can put adhesive on the back of the heater.
Inside the heater there are two types of heating way: one is resistance wire and another is heating film.
Application:
1. Industrial equipment, pipelines, barrels, tanks, etc.
2. Outdoors telecommunication equipment
3. Medical equipment and devices
4. Outdoors electronic devices
5. Thermal imaging of imaging equipment
6. Case protection under cold and moist environment
7. Industrial ovens and thermal processing equipment
Specifications:
Heat resistant temp | |
Continuous use | 200°C |
Max.temp | 250°C |
Power characteristics | |
Capcity tolerance | ±10 percent |
Insulation resistance | 1000M ohms or over/DC500V |
Withstand voltage | 1500V/1minute |
Measurements | |
Max. | 800mm×3000mm |
Min. | 25mm×50mm |
Thickness. | 1.5mm |
For one year guarantee period and the wroking life of design is 50000 hours to 100000 hours.
Company certification: ISO9001:2008, ISO 14001
