Hyking Cheap PTZ Tester CCTV Tester Cctv Tester Pro HK-TM803

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	Hyking
Model Number	HK-TM803

CCTV Tester
3.5"TFT-LCD,
LCD Brightness/Contrast/Color
Saturation adjustable: PTZ controller,PTZ data analyst.

CCTV Tester cctv tester pro HK-TM803

1) CCTV system installation and maintenance
2) Dome camera and All in one camera testing
3) The CCTV transmitting channel testing
4) PTZ controller

3.5"TFT-LCD , 960H×240Vresolution
DC12V power output
Audio input
Adjustable brightness, contrast, color of LCD
Video Level testing, video signals measured in IRE or mV
Automatically identify and adapt the video mode of NTSC and PAL
Colorbar Video signal generator, transmit/receive colorful images
Support more than twenty kinds of PTZ controller protocols. For example, PELCO-P, PELCO-D, SAMSUNG etc.
Capture the PTZ protocol to assist the setting personnel to find out the control protocol and therefore easily target the problematic equipment.
PTZ address scanning, search up the ID of PTZ camera.
Support RS232 and RS485 interface, the rate 150-19200bps
Powerful in testing LAN cable, measuring the connecting status and displaying the sequence of connection
PTZ(P/L & Zoom) Control: Control the status of P/L, zoom in/out the camera, adjust the aperture, foci and setting parameters, run and call the preset.
PTZ address scanning, search up the ID of PTZ camera
Lithium Ion Polymer Batteries(3.7V DC2000mAh), more reliable, and work 11 hours
Easy to use that the train is almost unnecessary

Model/Item	HK-TM803 CCTV Tester
Video Test
Signal mode	NTSC/PAL (Auto Adjust)
Display	3.5 inch TFT-LCD ,960 x 240 resolution
LCD adjust	Adjustable brightness, contrast, color of LCD
Video IN/OUT	1 channel BNC Input & 1 channel Output
Video Output Mode	1.0 Vp-p
Video Level test
Level test	Video signals measured in IRE or mV
Power Output
Power output	DC12V, 1A
Audio Test
Audio input	1 channel Audio input
PTZ controller
Communication	RS232, RS422 simplex and RS485
PTZ Protocol	Compatible with more than 20 protocols such as PELCO-D/P, Samsung, Panasonic, Lilin, Yaan, etc.customized
Baud Rate	150,300,600,1200,2400,4800,9600,19200bps
Video Signal Generation
Color bar generation	Output 1 channel color bar video signal for testing monitor
UTP CABLE TEST
UTP cable test	Test UTP cable connection state and display in the screen. Read the number of the test box.
PTZ data Capture and display
PTZ Data Test	Capture and Analyze the PTZ data sent from controlling device
PTZ address scanning
PTZ address scan	Search up the ID of PTZ camera
POWER
Power Adapter	DC5V, 2A
Battery	1 pcs Lithium Ion Polymer Batteries, 3.7V DC2800mAh
Rechargeable	4 hours recharging time, work for 15 hours
Low Consumption	Sleeping mode, display battery power state
Other Parameters
Work Temperature	-10---+50
Work Humidity	30%-90%
Dimension/Weight	94mmx175mmx40mm / 360g
