Automatic induction sealer

Application

The machine is applicable to seal container in any type of plastic material, as well as glass.

Packing Processing :

The main operation process as follow: Rotate tightly container lid with aluminum foil compound pad inside, then conveyer belt carries containers to pass under induction generator, at the moment, Aluminum Foil is fused onto the mouth of container by instantaneous heat caused by electromagnetic induction. Sealing is achieved. If there exists some rough articles on sealing mouth, that will not be any passive affection on sealing.

Features

1.With function of self-examination, machine could be protected against over-voltage and over heat.

2.With cooling system by Bi-auto circulation of water cooling in cooling off induction generator and power  module,  machine automatically cut off high tension power source right away in case water source is blocked.

3.The machine is appreciated by its adjustable power, high sealing speed. Powerful adhesive force, effective in separating aluminum and its paper  pad. It matches assembly line.

4.  ♦ Stainless outer shell

    ♦ Drilling by digital controlled punch

    ♦ Clean and elegant in outline

    ♦ Conveyer belt is made by engineering plastic link joint

    ♦ Speed of conveying container is adjustable.

    ♦  Applicant material: PEPETPPPVCABS and glass bottle.

Technical Parameters:
