Galvanized steel stranded wire /stay wire /guy wire/swg wire 5/8 (19/3.18mm)

FOB Price

US$ 1 - 10 / Meter

1000 Meters(Min. Order)

Port Qingdao or Shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Henan, China	Brand Name	Sanhe
Model Number	steel wire	Insulation Material	Other, bare
Type	Other, all voltage level, stranded	Application	Other, power station,construction,transmission ,etc
Conductor Material	Other, steel	Jacket	Other, bare

Product Description

1.Product specifications.

5/8" Galvanized Steel wire strand produced as per ASTM 475 Class A EHS Grade ,used for guy wire with heavy corrosion zinc-coating.

Name:Zinc-coated Steel Wire(Galvanized Steel Wire Strand)

Number of wire: 19 wires

Strand Diameter: 5/8"

Grade:EHS Grade

Breaking Strength of Strand:178.819KN

Weight of zinc-coating: ≥ 259g/m2

Elongation(L=610mm): ≥ 4%

Lay: left hand

Surface: hot dipped galvanized

Raw Material: Q195,Q235,45#, 60#,65#, 70# ,80#,82B# carbon steel

Packing length:250ft /500ft /1000ft /2500ft /5000ft /wooden reel on pallet

2.Zinc- Coated of steel wire strand Grade

Class A and Class B

3.Standard : ASTM A475 , ASTM B498 ,BS183:1972 ,IEC ,GB , ASTM A363

4. Application : Galvanized steel wire strand /guy wire /stay wire is used for ACSR Core , pulling pole ,overhead conductor, Messenger wire ,Static wire,Guy wire,Guide rail cable

5 .Specification : galvanized steel wire strand /steel strand wire /guy wire /stay wire

•ASTM A-363 Zinc-Coated (Galvanized) Steel Overhead Ground Wire Strand
•ASTM A-475 Zinc-Coated Steel Wire Strand
•ASTM A-925 -5 % Aluminum-Mischmetal Alloy-Coated Steel Overhead Ground Wire Strand
•ASTM A-855 Zinc-5 % Aluminum-Mischmetal Alloy-Coated Steel Wire Strand
•ASTM A-640 Zinc-Coated Steel Strand for Messenger Support of Figure 8 Cable.

Application

Post Tensile projects

Mainly used as auxiliary reinforcing strand for concrete structure.e.g.long spannned bridges on railway and high way, overhead crane construction ,multi-floor industrial building

packing

NOTE:Providing engineer design as per customer's request.
