Product Details
Place of Origin | Shandong, China | Brand Name | Hilight Solar | |
Model Number | HSB-100 | Type | NI-MH | |
Nominal Voltage | 12V | Size | Other, 332*174*214*220 mm | |
Nominal Capacity | 100Ah |
Product Description
solar battery 12V 100AH for solar system
SPECIFICATIONS | ||||
Nominal Voltage | 12 V | |||
Rated Capacity (20 hour rate) | 100 AH | |||
Dimensions (Length*Width*Height*Total Height )/mm | 332*174*214 mm | |||
Weight Approx | 32 kg | |||
| ||||
CHARACTERIESTICS | ||||
Capacity 25°C | 20 Hour rate | 7 AH | ||
10 Hour rate | 6.51 AH | |||
5 Hour rate | 5.95 AH | |||
1 Hour rate | 4.2 AH | |||
|
| |||
Internal Resistance | Fully charged battery at 25°C | 25 m Ω | ||
Capacity affected by temperature (20 hour rate) | 40°C 25°C 0°C -15°C | 102% 100% 85% 65% | ||
Self-Discharge At 25°C | Capacity after 3 month storage Capacity after 6 month storage Capacity after 12 month storage | 91% 82% 64% | ||
Terminal Type | T1,T2 | |||
Charge (Constant Voltage) | Cycle use | Initial Charging Current less than 2.80 A Voltage 14.5~14.9V | ||
Float use | Voltage 13.6~13.8V |
12v 100AH lead acid Battery features:
- Maintenance free
- High power to weight ratio
- No memory effect
- Low self discharge
- CE certificate
- Long service life
- High discharge rate
- Wide operating temperature range
Warnings:
- Matrix series batteries have acid in the case and are fully charged before leaving factory.
Do not attempt to dismantle the battery, if accidental skin/eye contact is made with electrolyte,
seek medical advice immediately.
- Do not use a new battery with an old one.
- Do not use the battery in sealed container.
- Each battery should have detailed record including the ex-factory date, installing date and using record.
- Check the connection of wire in a fixed interval (once a year). If there is any looseness should tighten the wire.
- Wipe the surface of the battery with soft cloth in a fixed interval (once three months) and always keep the battery clean.
- Avoid using any kind of organic solvents for cleaning the surface of the battery.
Applications
- Fire protection and security uninterruptible power supply
- Electronic appliance and other backup power supply
- Telephone and telecommunication equipment
- Uninterruptible power supply systems for bank
- Emergency lighting or small lamp fitting
- Electric power system
- Security system
