Home > Products > Linear bearing > 30 mm Shaft Long Type Linear Motion Ball Bearings Lm30luu Bearing
30 mm Shaft Long Type Linear Motion Ball Bearings Lm30luu Bearing
- Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Brand Name | neutral 30 mm Shaft Long Type Linear Motion Ball Bearings lm30luu bear | Precision Rating | ABEC1,ABEC3,ABEC5,ABEC7,ABEC9,P0,P6,P5,P4,P2 | |
| Model Number | LM...L series | Place of Origin | Guangdong, China |
Product Description
Specifications
1.30 mm Shaft Long Type Linear Motion Ball Bearings lm30luu bearing2.SGS Audited 18 years bearing manufacture.
30 mm Shaft Long Type Linear Motion Ball Bearings lm30luu bearing Specifications
1.Structure : Cylinder
2. High accuracy.
3. Low noise and vibration.
4. ISO9001:2000 Quality.
5. OEM service.
6. Favorable price.
7. Inner diameter: 30mm
8. Outside diameter: 45mm
9. Numbers of ball rows: 4 rows.
10. Weight: 180g.
Applications:
Automobile,Motorbike,Electric tools ,Small appliances ,Textile machine,Printing machine, Fitness sports equipment,Medical device,Printer,Automatictellermachine,Modelairplane etc.
Precision rating: ABEC1,ABEC3,ABEC5,ABEC7,ABEC9,P0,P6,P5,P4,P2
Delivery time: 5-20days for standard,30days for non-standard .
Payment terms: L/C,T/T,Western Union.
Packaging details:
Tubes and cartons. We can provide other packaging materials according to customers' requirment.
More model, please check the following sheet.
| Long type linear bearings | ||||||||||
| LM…LUU Series | Major dimensions | Weight (g) | Basic Load Ratings | |||||||
| Type | Number of ball rows | dr (mm) | D (mm) | L (mm) | B (mm) | W (mm) | D1 (mm) | Cr Dynamic | Cor Static | |
| N | ||||||||||
| LM6LUU | 4 | 9 | 12 | 35 | 27 | 1.1 | 11.5 | 16 | 324 | 529 |
| LM8LUU | 4 | 8 | 15 | 45 | 35 | 1.1 | 14.3 | 31 | 413 | 784 |
| LM10LUU | 4 | 10 | 19 | 55 | 44 | 1.3 | 18 | 62 | 588 | 1100 |
| LM12LUU | 4 | 12 | 21 | 57 | 46 | 1.3 | 20 | 80 | 657 | 1200 |
| LM13LUU | 4 | 13 | 23 | 61 | 46 | 1.3 | 22 | 90 | 814 | 1570 |
| LM16LUU | 5 | 16 | 28 | 70 | 53 | 1.6 | 27 | 145 | 1230 | 2350 |
| LM20LUU | 5 | 20 | 32 | 80 | 61 | 1.6 | 30.5 | 180 | 1400 | 2750 |
| LM25LUU | 5 | 25 | 40 | 112 | 82 | 1.85 | 38 | 440 | 1560 | 3140 |
| LM30LUU | 6 | 30 | 45 | 123 | 89 | 1.85 | 43 | 580 | 2490 | 5490 |
| LM35LUU | 6 | 35 | 52 | 135 | 99 | 2.1 | 49 | 795 | 2650 | 6470 |
| LM40LUU | 6 | 40 | 60 | 154 | 121 | 2.1 | 57 | 1170 | 3430 | 8040 |
| LM50LUU | 6 | 50 | 80 | 192 | 148 | 2.6 | 76.5 | 3100 | 6080 | 15900 |
| LM60LUU | 6 | 60 | 90 | 211 | 170 | 3.15 | 86.5 | 3500 | 7650 | 20000 |
