Thermal Protector, Motor Protector

17AM thermal protector, thermal cutoff, thermal cutout, overload protector, motor protector, CD79F thermal protector

Snap action thermal protector , automatic reset type with UL,VDE, CCC , Rohs compliant

Work principle:

17AM series thermal protector is a temperature automatic response devide and is connected in series to the winding of motor. The contacts open on temperature rise and reset after the temperature drops down.

Application:

17AM-D series thermal protector has the following characters: the structure is advanced, the volume is very small, the action is sensitive, large in contact capacity, long life and so on. It’s widely used and protect electric motor; ballast of fluorescent lamp;transformer; DC motor of automobile; integrated circuit and general electric appliance.

Main features:

Terminals on same side or on opposite sides.

Contact rating: 125VAC 16A/ 20VDC 20A/ 250VAC 8A /250VAC 9A
Thermal switch dimension:23.0X10.6X4.7mm

Open Temperature: 50C to 180C,  in 5C increasement

Tolerance for open temperature: +/-5C

Suitable for most impregnation processes

Approval: UL,VDE, CCC, Rohs compliant

Advantage:

Advance equipments, automatic production line, large production capacity and high quality guaranteed.

 Dimension:

A type:

B type:

A type: with leadwire and with insulation sleeve, the cable and length can be made according to customer's request:

Production Equipments:

Bimetal forming machine:

Stabilization Oven:

Auto welding machine:

Auto assembly machine:

Testing machine:
