Home > Products > Drying Oven > KOMEG Laboratory High Temperature Vacumn Drying Oven
KOMEG Laboratory High Temperature Vacumn Drying Oven
- shenzhen
- T/T L/C D/P D/A
You May Like
-
KOMEG Sterilizing Drying Oven for Laboratories
-
KOMEG 800L Laboratory Industrial Vacuum Drying Oven
-
KOMEG Electric Drying Heat Sterilizer Intelligent Blast Drying Oven
-
KOMEG Laboratory Electrode Heating Drying Oven Price
-
KOMEG Industrial Hot Air Circulating Drying Oven for Sale
-
KOMEG Industrial Hot Air Dry Oven/Forced Air Circulation Drying Oven/Heat Air Cycling Dry Oven
Product Details
| Place of Origin | Guangdong, China | Brand Name | KOMEG | |
| Model Number | KOV | Power | Electronic | |
| Usage | Process Testing Machine |
Product Description
KOMEG Laboratory High Temperature Vacumn Drying Oven
Precise oven or cabinet dryers are mostly used for drying, baking, sterilization of non - volatile items and heat treatment test for mining enterprises, schools, medical and scientific research. Expecially for simultaneous drying of different kinds of polymers in small quantities for drying materials for trial molding. They can also be applied in electronic engineering, electroplating, and pharmacy, paint baking, printing industries, etc. for preheating or drying related products.
Specifications | ||||||
Model | KOV-50 | KOV-100 | KOV-200 | KOV-290 | KOV-500 | |
Interior size (W*H*D)mm | 400*350*350 | 450*500*450 | 600*600*600 | 600*950*500 | 800*1050*600 | |
Exterior size (W*H*D)mm | 1010*650*760 | 1110*800*1100 | 1260*900*1100 | 870*1590*640 | 1160*1760*880 | |
Capacity(KVA) | 3.5 | 3.5 | 4.5 | 4.5 | 6 | |
Power | AC220V±10% 1Φ 50Hz/60Hz | AC 380V±10% 3Φ4wire 50Hz/60Hz | ||||
Temp. range | 50 ºC~ 200 ºC( 300 ºC) | |||||
Temp. constancy | ±1.0 ºC | |||||
Temp. uniformity | ±2.0 ºC( 50 ºC~ 200ºC ) ±3.0 ºC( 101 ºC~ 200 ºC) | |||||
Heat up time | 50 ºC to 200 ºC within 50 min | |||||
Interior material | Stainless steel plate | |||||
Exterior material | Painted Stainless steel plate | |||||
Insulation material | Glass wool | |||||
Safety devices | No fuse breaker, over temp protection, ceramic fuse | |||||
Accessories | Recorder, insolating layer | |||||
Note: 1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations | ||||||
Specifications | |||||
Model | KOV-600 | KOV-720 | KOV-1000 | KOV-1800 | |
Interior size (W*H*D)mm | 1000*1000*600 | 900*1000*800 | 1000*1000*1000 | 1600*1400*600 | |
Exterior size (W*H*D)mm | 1360*1720*880 | 1300*1750*1000 | 1300*1750*1000 | 1600*1940*1200 | |
Capacity(KVA) | 6.5 | 7.5 | 8.5 | 9.5 | |
Power | AC220V±10% 1Φ 50Hz/60Hz | AC 380V±10% 3Φ4wire 50Hz/60Hz | |||
Temp. range | 50 ºC~ 200 ºC( 300 ºC) | ||||
Temp. constancy | ±1.0 ºC | ||||
Temp. uniformity | ±2.0 ºC( 50 ºC~ 200ºC ) ±3.0 ºC( 101 ºC~ 200 ºC) | ||||
Heat up time | 50 ºC to 200 ºC within 50 min | ||||
Interior material | Stainless steel plate | ||||
Exterior material | Painted Stainless steel plate | ||||
Insulation material | Glass wool | ||||
Safety devices | No fuse breaker, over temp protection, ceramic fuse | ||||
Accessories | Recorder, insolating layer | ||||
Note: 1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations
| |||||
1.Provide a series of stable and reliable precision oven, KOV precise oven inside the box dimension is divided into eight kinds of standard specifications, can meet various requirements.
2.Forced air supply circulation system and the special outlet design to ensure perfect humidity and temperature uniformity.
3.LED digital temperature controller, easy operation and bring you happy customer experience.
4.Air-exhausting Device is optional
5.Other ultra high temperature oven series can reach 500ºC are available upon customized.
Machine Parts
Name: Bock Compressor
Brand: Bock
Original: Germany
Compressor rack, high efficiency low energy consumption, low noise;
Electronic components
Name: Electric cabinet
Brand: Schneider, DANFOSS, Omron, Panasonic
Original: Germany, France, Japan
Top brand electronics, with full range of protection include overheat of blower fan motor, earth leakage protection, load short circuit protection, over temperature protection, over pressure protection and so on.
Control System
Name: Controller
Brand: KOMEG/SAMWON
Original: China/South Korea
It can control temperature and humdity constantly such as thermo-hygrostat mounted on, termperature, humidity, respectively, by setting the PID values for each interval can be precisely controlled and easy control via PC or mobile is possible.
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* Visiting our factory is highly welcomed.
After-Sales Service
* We will train you how to install, use and maintain the machine.
