Stainless Steel Low Noise Energy-saving 30% Climate Chamber for Led Light Testing

Stainless steel sheathed heater PID control Temperature Humidity Chamber for Battery testing

1. High Performance Temperature Humidity Chamber Application

Able to accurately simulate a wide range of complicated natural environments, and is suitable for reliability test in industrial products. Meet GB5170.2.3.5.6-95 standard requirements of environmental testing equipment and test methods for the basic parameters of electric and electronic products under the condition of humidity, low temperature, high temperature, and constant heat..

Insulation box:

wall material: high-quality carbon steel with static color spray

inner wall material: SUS304 # matte stainless steel plate

Insulation materials: rigid polyurethane foam insulation layer + glass fiber, thickness of 100mm

Door:

Heating wire was installed at the door frames to prevent condensation at low temperatures.

Humidifier:

Basin heated humidification

Stainless steel sheathed heater

Heater control: non-contact period, such as pulse width modulation, SSR (solid state relay)

Water level control devices, anti-dry unit heater

Refrigeration Technology

Nitrogen welding, two-stage rotary vane vacuum pump, ensure that the internal cooling system clean and reliable.

water tray located at the bottom of the compressor to ensure condensate water drain through pipe freely at the rear of the chamber.

2. KOMEG brand KM-5166 LCD Touch screen controller with PID control parameters setting

Display:

Temperature and humidity settings (SV) Actual (PV) value can be displayed directly,

Execution of the program can display numbers, Paragraphs, remaining time and cycles, running time display,

Program editing and graphic curve display,

Fixed or program operation status display,

7-inch TFT display screen.

Resolution:

Temperature: + 0.01 Deg C; Humidity: + 0.1%; Time: 1min

3. Temperature Humidity Test Chamber Main Technical Specifications Quick Know:
