bedding-towel packing machine in bangladesh

Condition	New		Function	Wrapping
Application	Food, Commodity, Other, Food, Commodity, Machinery & Hardware		Packaging Type	Bags, Other, Bags, flow
Packaging Material	Plastic		Automatic Grade	Automatic
Driven Type	Electric		Voltage	220V
Power	220V,50/60HZ,2.6KW		Place of Origin	Guangdong, China
Brand Name	SUK		Model Number	SZ-320B
Dimension(L*W*H)	(L)3770*(W)720*(H)mm		Certification	CE
After-sales Service Provided	Overseas service center available

Specifications

Packing Machine SZ-320B is suitable to pack various product.
1. Easy operation
2. Reliable performance





     Foshan SUK Packing Machinery Co., Ltd. specializes in producing pillow and vertical packing machines. We gather the design, produce and sales service in integral whole. It share large piece of market with high technology and good quality and service .



The machine as follows

towel packing machine in bangladesh

Packing material:Heat-sealable laminaterd film,such as: OPP,PE,PVC,PT/PE,OPP/CPP ,ather special sealable packing film



Sealing Type:Back-sealed( 3 sides sealed)



Option:Date coder/printer

Punch Hole System Auto falling device

Nitrogen Charging Device

Touch screen/Digital Display

Full Stainless Steel (304/201 ect)

Gas device for modified atmosphere packaging



towel packing machine in bangladesh

Rotary pillow packaging machine SZ~320B



I.FEATURES
1. Dual frequency conversion control,bag length can be set and cut in one step,saving time and film.

2. Interface features easy and quick setting and operation.
3. Self failure diagnosis,clear failure display.
4. High sensitvity photoelectric eye color tracing,numerical input of cutting sealing position for estra accuracy.
5. Temperature independent PID control,more suitable for packaging different materials.
6. Positioned stop function,without sticking knife or wasting film.
7. Simple driving system,reliable working,conwenient maintenance.
8. All control is runned through software,esay for function adjusting and technical upgrade.



II. APPLICATIONS

Packaging various kinds of regular objects like biscuits,pies,chocolates,bread,instant noodles,mooncake,medicine,daily appliances,industrial parts,paperboxes,plates,etc.



III. SPECIFICATIONS





Type	SZ-320B
Film width	Max.320mm
Bag length	65~280mm
Bag width	50~160mm
Product height	Max. 40mm
Film roll diameter	Max. 320mm
Packaging rate	40~230bag/min
Power	220V,50/60HZ,2.6KVA
Machine size	(L)3770×(W)720×(H)1450mm
Machine quality	700Kg
Remarks	optional air filling device











the packing machine:













The packing machine details:
