Home > Products > INDUSTRIAL WELDER > MMA INVERTER WELDING MACHINE
MMA INVERTER WELDING MACHINE
- Ningbo
- T/T
You May Like
-
TIG/ MMA/ CUT functional Inverter welding/cutting machine
-
ZXE1 THREE PHASE AC/DC ARC WELDING MACHINE
-
AC/ DC pulse Aluminium TIG/MMA Inverter welding machine
-
DC INVERTER NBC-350 MIG-500 IGBT CO2 WELDING MACHINE
-
DC MIG/MMA IGBT inverter welder NBC-270 270A
-
Wide voltage MIG/MMA IGBT inverter DC welder of ExpertMIG-5000 500A
Product Details
| Condition | New | Place of Origin | Zhejiang, China | |
| Brand Name | eDON | Model Number | MMA-250/300/400/500 | |
| Arc Current | 40-315 | Pulse Frequency | 50/60Hz | |
| Rated Duty Cycle | 60% | Dimensions | 570*310*470 | |
| Usage | welding mild steel,stainless steel,low alloyed steel | Voltage | 380V |
Product Description
ARC MMA INVERTER WELDING MACHINE
1. Single-phase, fan-cooled, thermostatic protection,movable welding cable.
2. Advanced inverter technology, superior arc performance.
3. "Weld anywhere" with light weight, comfort to carry.
ITEM |
MMA-250 |
MMA-300 |
MMA-400 |
MMA-500 |
Voltage/frequency | AC380V±10%50Hz/60Hz | AC380V±10%50Hz/60Hz | AC380V±10%50Hz/60Hz | AC380V±10%50Hz/60Hz |
Rate input capacity(KVA) | 9.5 | 12 | 12 | 12 |
Output current range(A) | 20-250 | 30-300 | 30-400 | 30-500 |
Arc force range(A) | 0-75 | 0-75 | 0-75 | 0-75 |
Duty cycle(%) | 60 | 60 | 50 | 50 |
Output voltage(V) | 30 | 32 | 35 | 40 |
No-load voltage(V) | 54 | 69 | 69 | 57.5 |
Efficiency(%) | 85 | 85 | 85 | 85 |
Power factor(COS) | 0.93 | 0.93 | 0.93 | 0.93 |
Usable electrodes(mm) | 1.6-4.0 | 3.2-5.0 | 3.2-6.0 | 3.2-8.0 |
Net weight(kg) | 22 | 25 | 28 | 35 |
Cross weight(kg) | 26 | 30 | 33 | 40 |
Protection class | IP21 | IP21 | IP21 | IP21 |
Insulation class | B | B | B | B |
Dimension(mm) | 480*205*355 | 580*334*480 | 580*334*480 | 580*334*480 |
