Home > Products > laminating Machine Series > HSHM1350TZ-H cheaper Paper Sticking Machine
HSHM1350TZ-H cheaper Paper Sticking Machine
- 5 Set / Sets per Month
- QingDao
- T/T
You May Like
-
HSHM1350TZ-F woodworking/pvc/grainy/plane sheet paper laminating machine
-
HSHM1350TZ-C plywood film laminating machine
-
HSHM1350TZ-D paper laminating machine for sheet
-
HSHM1350TZ-D paper roller pressing machine
-
HSHM1350TZ-F PVC&Paper sticking on board woodworking machine
-
HSHM1350TZ-F Paper sticking machine
Product Details
| Product Type | Other, Paper sticking machine | Processing Type | Other, overlay the PVC Ior paper on the boards | |
| Place of Origin | Shandong, China | Brand Name | HongSenHaoMai, HongSenHaoMai | |
| Model Number | HSHM1350TZ-H, HSHM1350TZ-F | Voltage | 380V | |
| Power(W) | 5.5KW | Dimension(L*W*H) | 7500*2100*1600MM | |
| Weight | 1200KGS | Certification | Other, ISO |
Product Description
Specifications
HSHM1350TZ-H paper sticking machine1 working width 1350mm
2 roller glue spreading
3 hot and cold pressure
4 ISO
HSHM1350TZ-H cheaper Paper Sticking Machine
APPLICATION OF HSHM1350TZ-H CHEAPER PAPER STICKING MACHINE
The paper sticking series are used to laminate the volumed decorative paper, the volumed PVC or the volumed protecting film on the surface of plan boards such as the MDF, the particleboard, the plasterboard and so on without bubble or wrinkle and with high efficiency.
Feathers of the HSHM1350TZ-H CHEAPER PAPER STICKING MACINE
1.It can finish the glue spraying, the paper sticking, the hot and cold press successively with high efficiency.
2.The rolls rising is controlled by pneumatic lifting system
3.The glue coating system adopts the overrunning clutch.
4.It is used to laminate the PVC. decorative paper, paint paper and luxirant paper on the surface on the wood or bamboo board, marble, plaster, steel and MDF.
TECHNICAL OF HSHM1350TZ-H CHEAPER PAPER STICKING MACHINE
MODEL | HSHM1350TZ-H |
Roller Specification | Φ190X1350mm |
Shortest work length | 500mm |
Working width | 1220mm |
Work thickness | 2-30mm |
Conveying speed | 1-25m/min |
Conveying Motor power | 1.1kw |
Brush motor power | 0.37kw |
Heating power | 2.4kw |
Pvc or paper width | 1280mm |
Overall dimension | 5980X1980X1780mm |
Net weight | 1900kg |
Make work width base on customer: 600/1000/1600/1800mm | |
SAMPLES AND MACHIN
MACHIENS AT THE FACTORY
PLYWOOD BOX PACKAGE WITH SIZE 3100*2200*1900MM
