vacuum distillation waste transformer oil recycling machine

Specifications

  Waste engine oil recycling vacumm distillation Base oil purfier system (Turnkey Plant)

1 >Dehydration and degassing ability.
(1)The equipment adopts vacuum pump unit which consist of pumps and large ventilation rate of displacement Roots vacuum to pump on the system, make the water vapor and other gases  removed fast.

(2)Adopts the international advanced technology of the short-range film evaporation and molecular separation technology, rapidly remove a large amounts of water contained in oil, while effectively remove the trace moisture in oil (less than 3ppm).

2> An exceptionally strong ability to filter out impurities.

Progressive encryption filtering system settings and the primary and secondary filters are made of stainless steel twill mesh imported from Japanese, can be cleaned and used repeatedly to reduce the operating costs of equipment; fine filter uses polymer filter imported from the United States, it is high precision, and can carry a large amount of pollutant, can effectively remove the fine particulate impurities in the oil, so that the oil cleanliness level after treatment can be up to NAS6 (NAS1638 level) or above.

3>Proper protective equipment makes the full realization of unmanned, automatic operation.

Through the implementation of a comprehensive protection with equipment temperature, liquid level, pressure, power off, super-pressure, under-voltage, overload by each power element, effectively prevent the accident and ensure the normal operation of equipment.

Techincal Indications:

Recovery rate

Base oil: 85%~87% (index similar to SN150~SN500)

Gasoline: 3%

Diesel:3%

Oil residue: 6%~9%

Systems of equipment

1. Pre-treatment system: waste oil will be pumped into the distillation kettle after pretreated.

2. Distillation system: through burning coal, gas or fuel oil to make the oil in the kettle up to the working temperature. This system equipped with stirring system and insulation system.

3. Cooling system: the gaseous hydrocarbon will be cooled into liquid base oil. Gasoline and diesel oil.

4. Oil storage system: the base oil, gasoline and diesel get from cooling system storage here, Then pump into the storage tank.

5. Vacuum system: meet the technology requirement.

6. Filtration system: rapidly filter out mechanical impurities in the base oil, gasoline and diesel, get the high quality base oil, gasoline and diesel.

Comparasion picture of the waste oil and the regenerated oil:

The black one is the used engine oil,and the red one is regenerated by our machine,and the light yellow is refined after  the used engine oil wasregenerated.

Complete Plant Includes:

1. Vacuum  system

2. Thermal  oil  heating  system

3. Electric control  cabinet

4. Technical  personnel  training

5. Technical  training  and  so  on.

Through survey and investigation, the equipment our company developed is originated in our country.

We have received national invention patents.

The number of invention patent is 200810141346.8

Utility model patent No.:ZL20082014967303

This equipment has been recommended as the first energy-saving products by Luoyang Municipal Government and good for popularization..

Simlar Projects:

Detail Show :
