NF-P High Speed Facial Tissue Folding Machinery
- Shenzhen
- T/T
You May Like
-
Napkin Manufacturing Automatic Handkerchief Paper Making Machine
-
High Precision Embossed Bumf Machine
-
Paper Napkin Folding Converting
-
Fastest New Design High Speed Automatic Printing Embossing Paper Towel Interfolder
-
Full-automatic Interfold Facial Tissue Paper Machine
-
Newest Full Automatic High Speed N Fold Hand Towel Machine
Product Details
| Condition | New | Product Type | Paper Napkin Machine | |
| Processing Type | Other, Printing embossing folding machine | Place of Origin | Guangxi, China | |
| Brand Name | Elitis | Model Number | NF-P | |
| Voltage | 380V | Power(W) | 2.75-4KW | |
| Dimension(L*W*H) | 4150*800*1600mm | Weight | 1500KG | |
| Certification | Other, CE, CE ISO9001/BV | Warranty | one year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Facial Tissue Folding Machinery1) High speed
2) High definition
3) 500-600sheets/min
4) Napkin tissue folding machinery
NF-P Printing/Embossing Napkin Folder can work on single&multi-ply TISSUE and MG.Makes table napkin, nicely printed, intensively embossed, square folded, precision cut, pre-counted and accurately stacked.Automatically at 400-600 pieces per minute. Fast and easy exchange of sizes. Versatility is the key-note.
Specification for NF-P High Speed Facial Tissue Folding Machinery
Model | NF-P (1-4color) |
Raw material size | ≤Φ1000*(230-460)mm,13-20gsm 1-2plies wooden pulp paper |
Core : 76mm | |
Button embossing roll | with wool-cloth,neoprene or wool-paper material. (it can be decided by the embossing patterns)
|
The embossing unit can be equipped with heating element t o keep the temperature of the embossing rolls (be used with paper embossing roll) | |
The printing pattern is changeable and customized | |
Printing unit | flexography and anilox roller applied |
Ink feeding | by pneumatic diaphragm pump, transfer by two rollers |
Precise color register device and printing rollers equipped | |
Folding forms | 1/4 1/8 quadrate and rectangled |
Unfolded size | 230*230-460*460,width adjustable |
Folded size | 115*115-230*230mm |
Folding rate | 560sheets/min 450sheets/min with printing |
PLC computer programmed control | |
Processing uni | hot air dryer |
Power | 2.75-4KW 3phase 380V 50HZ |
Overall size(L*W*H) | 4150*800*1600mm |
Weight | 1500KG |
Printing clearly, precision cut, accurately stacked ,running stably and high speed. Used to converting high quality napkin paper. | |
Here you will have a close view of NF-P High Speed Facial Tissue Folding Machinery
