High Speed and Hot Selling Easy Operation Small Facial Paper Automatic Machine

FOB Price

US$ 3,000 - 50,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Product Type	Other, small facial paper automatic machine
Processing Type	Paper Folding Machine	Place of Origin	Guangxi, China
Brand Name	Elitis	Model Number	FM-200
Voltage	380V	Power(W)	5.5KW
Dimension(LWH)	4800 x 1800 x 2100 mm	Weight	1500 KG
Certification	CE	Warranty	One Year
After-sales Service Provided	Engineers available to service machinery overseas

small facial paper automatic machine
1 CE compliant
2 Full Automatic
3 Electric inspection system
4 High speed

Technical parameters of small facial paper automatic machine

Machine model	5 lanes; (Customized Up to 9 lanes.)
Use	Production of facial tissue machine or V fold hand towel
Sheet size	200 x 210 ± 2 mm; Other sizes please specify.
Folded size	100 x 210 mm ± 2/100 x 170 mm ± 2;
Parent Roll Size	210 x 3/630 x 1100 mm diameter
Parent Material	13-16g/m2 Two plies wood pulp tissue paper or others.
Raw material core diameter	3’’ (76.2 mm); Other sizes please specify.
*Folding speed*	*700-1000 pics/min x 5 lines or 160-200 m/min*
*Program control*	Frequency speed control; PLC; Electric inspection system
Embossing unit	Steel to rubber embossing; steel to steel embossing(optional).
Button embossing roll	Felt roller; paper roller; rubber roller(optional).
Edge embossing; Calendaring	Optional
Web guiding system	Optional
Air pump power	7.5-30 KW
Pneumatic system	3 HP air compressor; mini pressure 5 kg/cm2 pa (Provided by client).
Main motor power	5.5-11 KW
Machine Size	4800 x 1800 x 2100 mm
Weight	1500 KG

For more details or related products please visit our website or contact us,thanks!
