HB-3000 Digital Display Brinell Hardness Tester of Steel

FOB Price

US$ 999 - 5,999 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China		Brand Name	hensgrand
Model Number	HB-3000

High precision reading microscope measurement system

Mechanical structure patent design, low noise with extremely low failure rate

Electronic reversing switch

Accuracy accord with GB/T231.2, ISO6506-2 and the United States ASTM E10standard

Model	HB-3000
Measuring range	8-650HBW
Test force	1838.8,2415.8,7355.3,9807,29421N(187.5,250,,750,1000,3000kgf)
Max. height of test piece	230 mm
distance between Pressing head center and the wall	120 mm
Min. scale value	AC380/220V,50/60Hz
Dimension of the external form	466 x 238 x 630mm
Net weight	approx. 210 kg

Standard accessories

Descriptions	Quantity
Large testing platform	1 pc.
Small testing platform	1 pc.
V-notch testing platform	1 pc.
Tungsten carbide steel ball indenter	1 pc. Φ2.5,1 pc. Φ5,1 pc. Φ10
Rockwell standardized block	2 pcs.
20 times readings microscope	1 pc.
Instruction manual	1 share
Packing list	1 share
