hvac Air Handling Unit system

Specifications

Air Handling Unit

1. Modular design, convenient to assemble

The components are standardized, and common in application, it makes convenient in assembly and maintenance, 330mm is the basic value for each module (Refers a "M" in following), the machine dimension can be changed with flexibility to meet the clients' requirement to maximum limit. We provide the users with 25 standard and 52 non-standard configurations, there is 77 kinds of models, 385 kinds of specification, for option, and there are more than 20 types of functional section for each model.

It's framework construction, can be flexibly assembled at site. The site assembly, maintenance and dismental is convenient for its scientific modular design, especially for units of large or extra large size.

2. Elegant appearance and good performance of insulation

A.The unit adopts aluminum alloy frame and compound aluminum alloy of high strength.

B. Heat isolation panel

3. Pefect sealing panel

The cabinet uses special PVC sealing structure that looks like a maze, minimizing air leakage.

4. Various functional sections

The air handling unit has sections followed: mixing section, preliminary filter section, medium filter section, sub HEPA filter section, HEPA filter section, cooling coil section, humidifier section, heating section, sterilization section, sound attenumator section, heat recovery section. air supply section, air discharge section and so on.

5. Low noise

Adopts double inlets forward curved centrifugal fan motor, and strict static and dynamic test has proved its stable and low noise operation. Adopt world brand fan bearings is hermetic style, no need to charge lubrication oil and any other maintenance, since it can auto-lubricate, auto-adjust core, auto-lock, auto-shuttle,etc.
