12mmx200mm Narrow Steel Plates Straightening Machine

Specifications

                        12mmx200mm narrow steel plates straightening machine

The technical parameters of  12mmx200mm narrow steel plates straightening machine  :

a.  applied to : carbon cold rolled coils

b.   material quality : first class steel coils of the international standard

c.   tensile strength:δb≤500Mpa

d.   thickness:4-12mm

e.   width :200(Max)

f.    diameter of leveling rollers:φ180

g.  distance of leveling rollers:190mm

h.  material of leveling roller:42CrMo, hardness:HRC52-60

The brief intrducion of 12mmx200mm narrow steel plates straightening machine  :

12mmx200mm narrow steel plates straightening machine:

1.It makes uneven steels even and guide them to the right following process. It also do the fixed length cutting and fixed quantity packing to the plates.

2.It is composed of 11 working rollers, driving device, and machine frame. Both sides of each rolling wheel is transmitted by roll bearing , except the code rollers, all are the main force rollers.

3.The working rollers use 4.4kw electric machine to adjust the upper and lower gap through the turbine decelerator box to make sure the even quality.

4.Drive model: all the independent rollers and gear box are driven by 30Kw DC electromotor and decelerate by decelerator . And it is composed of the gear distributor and all-round coupling as well as the hydraulic brake devices and so on.

Pictures shows of 12mmx200mm narrow steel plates straightening machine :
