Vertical Small Food Packing Machine
- Ningbo or Shanghai China port
- T/T
You May Like
-
High Speed Multi-line Small Packet Packing Machine
-
Automatic Multi-line Back Seal Vertical Bagging Machine
-
Multi-line Vertical Back Seal Packing Machine for Food
-
Vertical Automatic Multi-lane Packing Machine
-
DXDF320 Vertical Multi-line Sugar Back Seal Packing Machine
-
DXDF320 Automatic Vertical Back Seal Multi-lane Packing Machine
Product Details
| Condition | New | Application | Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical | |
| Packaging Type | Bags, Pouch | Packaging Material | Paper, Plastic | |
| Automatic Grade | Automatic | Driven Type | Pneumatic | |
| Voltage | 380V/ 50HZ | Power | 8KW | |
| Place of Origin | Zhejiang, China | Brand Name | Jienuo | |
| Model Number | DXDK320 | Weight | 1.6t | |
| Dimension(L*W*H) | 1200*1400*2600mm | Certification | CE | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Usage:
The machine comprised by servo driven ,packing screw, mixing screw, hopper, storage. Using screw to feed and make a quantitative measurement.
The overall material on silo formed convection and moving driven powder material go down. According to the length and speed of whirling time control the size odf material volume. So it is easy to operate. Only to adjust the parameter to control the amount of loaded at the interface.
DXDF320 stick packing machine for powder takes the international advanced screw propelling type of feeding. Mainly to the filling powder, it is running fast, highly precision measurement and easy to adjust.
Main Parameter | |
Filling materials | Powders and less liquid materials, etc. |
Maximum width of packaging materials | 320mm |
Bag width | 15-40mm |
Bag length variable range | 35-200 |
Dimensions(L*W*Hmm) | 1.1mX1.2mX2.2m |
Package material core diameter | Φ70—Φ76mm |
Total power(Kw) | 8kW |
Measurement accuracy | ±5% |
Power Specifications | 380V 50Hz |
Air consumption | 0.25m3/h |
Weight | 1350kg |
Maximum width of packing material | 380mm |
Maximum diameter of packing material | Φ300mm |
Cross-cut frequency (times / min) | Up to 35 beats / min, it will be different depending on the package. |
Maximum capacity | Up to 40 bag/min |
1. Any questions in technical can contact us by e-mail and deal with it.
2. Spare parts replacement and repair service.
3. Engineer can be distributed into overseas required.
Wenzhou Jienuo Machinery & Technology Co., Ltd. is a manufacturing and trading company which is
mainly engaged in development,production and related services for pharmaceutical industry, food industry,
cosmetics industry, stationery industry, etc.
We have been the manufacturer of packing machines for 10 years. If you are interested in our utomatic
packing machines, please contact me without hesitation. we will give you the best price.
Anny
Company: Wenzhou Wenzhou Jienuo Machinery & Technology Co. Ltd
Tel : 0577-66856266
Fax: 0577-66856268
Mobile:15067768988
Q1. What's payment terms ,trade terms you accept ?
Usually we appreciate T/T 30% deposit , then 70% balance is paid before shipment , we usuallyoffer fob
ningbo price .but we also accept other way like L/C , wetern union ,and do CFR&CIF etc.
Q2. Does it easy to operate and what can i do if it doesn't work?
First ,our machine is stable and easy to operate by one man ,what you do is just learn some basic thing
like how to operate PLC .And we will sent you manual and video ,we suggest you to come to visit our
factory to learn more thing by yourself , and if there is something goes wrong , you can call us ,video-chat,
email us .And we will give solutions within 36 hrs .Our engineer also can be distributed to overseas as
you required.
