Low Cost Oscilloscope Digital Multimeter Uni-t
- shenzhen
- T/T L/C D/P D/A Credit Card
You May Like
-
Manual Range Electrical Good Digital Multitester UT39E
-
4000 Counts Multifunction China Digital Multimeter With Environmential Measurement
-
Low Price Digital Multimeter,best Cheap Multimeter UT54
-
F/NF 2 in 1 Type Probe Gold Plating Thickness Measurement on Any Metal
-
320 x 240 TFT LCD Mil Thickness Gauge on Steel or Iron
-
2 in 1 Type Paint Testing Gauge Magnetic Thickness Gauge for Automove
Product Details
| Place of Origin | Guangdong, China | Brand Name | UNI-T | |
| Model Number | UT81B | Measuring Current Range | 400μA/4000μA/40mA/400mA/4A/10A | |
| Measuring Voltage Range | 400mV/4V/40V/400V/1000V | Measuring Resistance Range | 400Ω/4KΩ/40KΩ/400KΩ/4MΩ/40MΩ | |
| Measuring Capacitance Range | 40nF/400nF/4μF/40μF/100μF | Dimensions | 179mm*88mm*39mm |
Product Description
low cost oscilloscope digital multimeter uni-t
| Specifications | Range | Best Accuracy |
| Model | UT81B | |
| DMM Specifications | ||
| DC Voltage (V) | 400mV/4V/40V/400V/1000V | ±(0.8%+8) |
| AC Voltage (V) | 4V/40V/400V/750V | ±(1%+15) |
| DC Current (A) | 400μA/4000μA/40mA/400mA/4A/10A | ±(1%+8) |
| AC Current (A) | 400μA/4000μA/40mA/400mA/4A/10A | ±(1.5%+8) |
| Resistance (Ω) | 400Ω/4KΩ/40KΩ/400KΩ/4MΩ/40MΩ | ±(1%+5) |
| Capacitance (F) | 40nF/400nF/4μF/40μF/100μF | ±(3%+8) |
| Frequency (Hz) | 10Hz-10MHz | ±(0.1%+3) |
| Scope Specification | Range | Best Accuracy |
| Bandwidth | 8MHz | |
| Real-Time Sample Rate | Constant sampling rate (peak sampling) | 40MS/s |
| Vertical Accuracy | ±(5%+1) | |
| Input Sensitivity | 20mV/div - 500V/div(1-2-5) | √ |
| Horizontal Accuracy | ±(0.1%+1) | |
| Time-Base Range | 100ns/div - 5s/div(1-2-5) | √ |
Side View : streamline design
| Display Count | 3999 | |
| Auto Range | √ | |
| Duty Cycle | 0.1 ~ 99.9% | √ |
| Diode | √ | |
| Auto Power Off | Can set their own | √ |
| Continuity Buzzer | √ | |
| Display | 160 x 160 Monochrome | √ |
| Trigger Types | Free Run/Normal/Single Shot | √ |
| Memory | 10 screens and setups | √ |
| Contrast and Bright Setup | √ | |
| Low Battery Indication | √ | |
| USB Interface | √ | |
| LCD Backlight | √ | |
| Input Impedance for DCV | ≥10MΩ | √ |
| Power | 1.5V Batteries(R6)X 4 | |
| LCD Size | 60mm X 60 mm | |
| Product Color | Red and Grey | |
| Product Net Weight | 498g | |
| Product Size | 200mm X 100mm X 48 mm | |
| Standard Accessories | Batteries, Test Lead,Alligator Clip,USB Interface Cable,PC Software CD, BNC Probe | |
| Standard Individual Packing | Gift Box, English Manual | |
| Standard Quantity Per Carton | 20 PCs | |
| Standard Carton Measurement | 490mm X 385mm X 510mm (0.096 CBM Per Standard Carton) | |
| Standard Carton Gross Weight | 24 Kg | |
| Optional Accessories | Scope Probe,AC Power Adaptor | |
