Stairs Glass Railing Prices Outdoor Stair Steps Lowes Stainless Steel D Type Middium Glass Clamp
- SHANGHAI
- T/T D/P D/A
You May Like
-
Stairs for Small Houses Stainless Steel Pipe Mounting Glass Clamp Stainless Steel D Type Middium Glass Clamp
-
Wrought Iron Window Modern Stainless Steel D Type Middium Glass Clamp
-
Profiles for Glass Clamp Stainless Steel D Type Midium Glass Clamp in Balustrades and Stairs
-
Stainless Steel Round Curved Back Glass Holder 30mm Glass Adapter Stainless Steel Standoff Glass Holder
-
Stair Railling Stianlesss Steel Square Glass Clamp Glass Fittings
-
Tracking International China Post Stianlesss Steel Square Glass Clamp Glass Fittings
Product Details
| Place of Origin | Zhejiang, China | Brand Name | SCHMIED | |
| Model Number | S11.4563.33 | Material | Other, Stainless Steel, AISI 304/AISI 316 |
Product Description
GLASS CLAMP DESCRIPTION
1) Material: stainless steel AISI304, AISI316 /Zinc Alloy
2)Surface: satin/mirror/electroplating
3) Type: glass clamps D wide type/square type/round type
4) Please order gaskets to suit appropriate glass
5) Fix to posts with blind rivet nuts and cap screws or Fdrill
6) Glass Clamp can support approx.50-80kgs per 2 clamps vertically positioned
7) Accessories available:rubber/screws/screw caps/safety pin/side plate
GLASS CLAMP- MIDDLE D TYPE
| Item No. | S11 system glass clamp |
| Description | Glass Clamp 63*45*28 with safety Pin suit for 8~12.76mm thickness glass 33.7mm tube S.S.304/316satin polish |
| Type | Middle "D" type glass clamp |
| Size | L:63mm "L"measurement for S11.4563.33 is from centre of radius of glass clamp |
| H:45mm | |
| W:28mm | |
| Suit Glass | 8/8.76/10/10.76/12/12.76 |
| Suit Post | 33.7~50.8mm |
| Material | AISI304/ AISI316 |
| Finish | Satin/Mirror |
| Base Desigh | curved base |
| Feature | No Hole Drilling;Pressure fit or 10mm -12mm diameter hole required if using provided security pin for glass support |
| Position | Stair Railings;Indoor/out door Railing;handrails;Deck,seaside;Swimming Pool Fencing;Balcony; |
| Accessaries | Rubber Gaskets;ScrewS;Screw cover Caps,security pin |
Glass clamp ||glass clamp ||glass clamp||glass clamp ||glass clamp ||glass clamp ||glass clamp ||glass clamp ||glass clamp ||glass clamp ||glass clamp ||glass clamp ||glass clamp ||glass clamp||glass clamp
Why Choice Schmied?
1) With over 12 years of experience in manufacturing in the field with glass clamps, handrail accessory and balustrade as well as.
2) Sales good in Europe, Australia, Germany,Australia,Asia,africa and so on.
3) Payment:30%~50% TT advance,Other balance is paied off at sight of copy B/L
4) Provide Professional experience and support special design as per requests
5) High quality and competitive price
6) OEM&ODM more than 9 years
