Easy-Folding Pavement Electric Mobility Scooter

FOB Price

US$ 1,050 - 1,300 / Unit

10 Units(Min. Order)

Port ShangHai

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	sweetrich
Model Number	SW1000F	Power	201-500w
Voltage	Other, 24v	Certification	CE
Charging Time	6-8h	Foldable	Yes
Range Per Charge	Other, 20km	Tire Size	8 inch

Product Description

Dimensions
Overall Length	1030mm
Overall Height	900mm
Overall Width	570mm
Weights
Total weight including batteries	36.5kg
Total weight excluding batteries	33kg
Maximum Loads
Max.user's weight	120kg
Max.load in the front basket	10kg
Max.loading persons	1
Driving Features
Max.speed forward	8Km/h
Min.speed forward	2Km/h
Reverse speed	5Km/h
Turning radius	140cm
Ground clearance	4cm
Max.cross obstacle height	5cm
Max.driving slope	10 degree
Max.driving range	20km
(Range depends on the circumstances during use,it can be less when hills,wind or loose surface such as gravel or sand.Range can also be vary under theuser's weight)
Driving System and Tires
Drive system	rear wheel with gear box
Motor	24V/270W
Controller	24V/50A
Brake system	eletro-magnetic parking brade Tires
PU tire size	8x2.5
Tire size(inflatable)	8x2.5
Batteries and Charger
Batteries	li-ion 24V/14Ah
Battery charger	120-230V/24V/2A
Max.charger current	2A
Charging time to 80% charge	6H
Charging time to full charge	8H
Additional Datas
Seat width	380mm
Backrest height	340mm
Seat depth	360mm
Armrest height from seat	210mm
Seat height from scooter platform	400mm
Optional Accessories
Seat belt for additional stability
External charger adapter for charging batteries not mounted to the scooter

We Guarantee:

1 year warranty for scooter & wheelchair & battery;1 year for Electronic control system; 3 years for frame & other metal parts; Within warranty free accessories & video provided,free training service,life-time technical support service
