Folding Electric Mobility Scooter SW1000F

FOB Price

US$ 1,200 - 1,300 / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	SWEETRICH
Model Number	Electric mobility scooter SW-1000F	Power	201-500w
Voltage	Other, 24v	Certification	CE
Charging Time	6-8h	Foldable	No
Range Per Charge	40-60km	Tire Size	8 inch

Dimensions
Overall Length	1030
Overall Height	900mm
Overall Width	570mm
Weights
Total weight including batteries	36.5kg
Total weight excluding batteries	33kg
Weight of the frame with seat	/
Weight of the frame no seat	/
Maximum Loads
Max.user's weight	120kg
Max.load in the front basket	10kg
Max.loading persons	1
Driving Features
Max.speed forward	9.7Km/h
Min.speed forward	2Km/h
Reverse speed	5Km/h
Turning radius	140cm
Ground clearance	4cm
Max.cross obstacle height	5cm
Max.driving slope	10 degree
Max.driving range	25km
(Range depends on the circumstances during use,it can be less when hills,wind or loose surface such as gravel or sand.Range can also be vary under theuser's weight)
Driving System and Tires
Drive system	rear wheel with gear box
Motor	24V/270W
Controller	24V/45A
Brake system	electro-magnetic parking brake
PU solid tire size	7x2.5 Front 8 x3 Rear
Tire size(inflatable)	/
Tube size	/
Tire pressure	/
Batteries and Charger
Batteries	LiFeP04 Battery 12V/15Ah
Battery charger	120-230V/24V/3A
Max.charger current	2A
Charging time to 80% charge	6H
Charging time to full charge	8H
Additional Datas
Seat width	380mm
Backrest height	340mm
Seat depth	360mm
Armrest height from seat	210mm
Seat height from scooter platform	400mm
Optional Accessories
Seat belt for additional stability
External charger adapter for charging batteries not mounted to the scooter
