Adjustable sieve dip jigger

FOB Price

US$ 10,000 - 100,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin

China

After-sales Service Provided

Engineers available to service machinery overseas

Adjustable sieve dip jigger is widely applied to treat lump coal, tailing coal, coal washing of non-grading, grading and both combined.

Features:

Adjustable sieve dip jigger has the features of the following:

(1) Larger capacity: single unit capacity will increase more than 20% than other type jigger of same specification.

(2) High efficiency: quantity efficiency will raise more than 3~5%.

(3) High productivity: the productivity of cleaned coal will increase more than 2%.

(4) I value is less than 0.2.

Technical parameters:

Technical parameters of KT.SKT serial jigger

Model No.		HKT.SKT-4.5	HKT.SKT-5.0	HKT.SKT-5.6	HKT.SKT-6.0	HKT.SKT-7.0
Feed coal size (mm)		0~80
Capacity (t/h)		40~90	45~100	50~110	55~120	65~140
jigging area (m2)	coal gangues section	1.8	2.0	2.24	2.4	2.8
	middle coal section	1.8	2.0	2.24	2.4	2.8
	extra section	0.9	1.0	1.12	1.2	1.4
	total	4.5	5.0	5.6	6.0	7.0
sieve plate dip(^o)	coal gangues section	adjustable range(0~5)
	middle coal section	adjustable range(0~5)
	extra section	1.5
screen mesh diameter(mm)	coal gangues section	15	15	15	15	15
	middle coal section	12	12	12	12	12
	extra section	6	6	6	6	6
Machine weight(T)		16	18	20	22	24
Weight of machine and materials(T)		45	50	55	60	65
