0-150mm accuracy vernier caliper

Specifications

SPECIFICATIONS

1.caliper length : 23.6cm

2.packing details:

3.material: stainless steel(4cr13)

TECHNICAL SPECIFICATIONS

1.Outside Jaws:           Measure External Length

2.Inside Jaws:              Measure Internal Length

3.Measuring Range:       0-150mm/0-6in, 0~200mm/ 0~8 in

4.Resolution:                  0.01mm/ 0.0005in

5.Accuracy:                     ± 0.02mm/ 0.001in (<100mm)

                                    ±0.03mm/0.001in(>100-200mm)

6.Repeatability:               0.01mm / 0.0005in

7.Max Measuring Speed: 1.5m/sec, 60in/sec

8.Measuring System:       Linear Capacitance measuring system

9.Display:                         LCD Screen

10.Construction Material:  Stainless Steel

11.Power:                          One alkaline lithium button cell battery 1.5v,TYPE LR44.

                                      Capacity-180MAH

12.Working  Temperature: 5°c-40°c/41 to 104 degree F

13.Note:            Accuracy affected in environments exceeding 80% relative humidity.

•APPLICATIONS

1.Operation : slider can be removed only after the locking screw (#10) is loosened.

2.Basic measuring methods :

1) loosen the locking screw

2) Press "ON " button, select sae or metric measurement by pressing "MM/INCH" button.

    Pressing "MM/INCH" button after measurement will display the sae / metric conversion.

3)To reset display to zero, close external measuring jaws, then press "ZERO" button.

MAINTENANCE INSTRUCTIONS

1. Keep the calliper clean and dry (liquid can damage the slider)

2. Use a clean, dry cloth to clean all surfaces -do not use solvents or solvent based cleaners.

3. To save power, turn off the unit when not in use.

Avoid contact with electricty and /or electronic devices

BATTERY REPLACEMENT

Flashing display indicates low battery. To replace battery, remove battery cover by sliding cover in

the direction indicated and replace battery with positive side facing out.
