Hydraulic Corrugated Steel Roof Sheet Roll Forming Machine Prices, Double Deck Roof Sheet And Tile Roll Forming Machine
- ningbo/shanghai for hydraulic corrugated steel roll forming machine prices
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Metal Galvanized Dual Level / Double Layer Roofing Sheet Roll Forming Machine
-
New Metal Glazed Double Layer Roof Sheet Roll Forming Machine / Corrugated Roof Sheet Making Machine
-
Corrugated Metal Wall And Roof Tile Making Machine / Double Layer Steel Roof Sheet Roll Forming Machine
-
Double Deck Aluminium Roofing Sheets Rolling Forming Machine, Step Tile And Roof Double Layer Roll Forming Machines
-
New Type Two Profile Colored Zinc Steel Roof Plate Double Layer Roll Forming Machine
-
China Manufacturing Corrugated And IBR Profiles Double Layer Roof Sheet Roll Forming Machine
Product Details
| Condition | New | Type | Tile Forming Machine | |
| Tile Type | Colored Glaze Steel | Use | Roof | |
| Production Capacity | 10-25m/min | Place of Origin | Zhejiang, China | |
| Brand Name | bluesteel | Model Number | bl | |
| Power(W) | 8.5kw | Voltage | 380V 3phase 50Hz. | |
| Dimension(L*W*H) | 15*1.5*1.5M | Weight | 8000KGS | |
| Certification | ce | Warranty | 14months for hydraulic corrugated steel roll forming machine prices | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Hydraulic Corrugated Steel Roof Sheet Roll Forming Machine Prices, Double Layer Roof Tile Roll Forming Machine
Specifications
double layer roll forming machine
1.roll forming machine workflow
2.roll forming machine main parameter table.
Material thickness | 0.3~0.7mm |
Material yield stress | 230~550 Mpa |
Max. forming speed | 8~25m/min |
Roller material | 45# steel with chrome treatment |
Roller driven type | Chain transmission |
Controller & operation | PLC & touch screen and button |
Hydraulic system pressure | 12 Mpa |
Hydraulic station motor power | 3 Kw |
Main motor power | 4~7.5Kw |
Total power | 7~10.5Kw |
Total weight | About 6000~8000 Kgs |
3.roll forming machine standard component:
4.optional component:
We can customize the products according to customer ' s requirements
Showroom
5.company advatage:
1)we have about 12 years experience in the steel roll forming machines for the design and produce there are much experience and professional people.
2)quality control,we have CNC process to produce the rollers,grinder machine to smooth the frame.make more precise.and less tollerance.and after assebling,inspect the whole machine and result before delivery.
3)we have professional engineer in charge of installation abroad.after services are easy way solution.
4)on time delivery.
5)quality garantee,one year time garantee,and service all the life.
6.roll forming machine Loading photos:
7.roll forming machine Application:
