Dual fiber 8 Channel Optical DWDM Mux Demux
- shenzhen
- T/T L/C Credit Card PayPal Other Cash
- 5 days
You May Like
-
1270~1610nm wavelength 16 channel single fiber cwdm mux/demux With UPG port
-
Gain 25dB Max output 18dB BA booster DWDM EDFA
-
Gain 25dB output 15dB Line LA EDFA amplifier
-
Use for dwdm long hual distance system PA pre-amplifier DWDM EDFA
-
C-band Erbium Doped Fiber Amplifier amplifying optical signals in optical transmission systems
-
WDM System Optical Line Protection OLP 1+1 power supply backup system
Product Details
| Brand Name | XYT | Place of Origin | China | |
| Model Number | XYT-DWDM-1*8-1008 |
Product Description
8 Channel Optical DWDM Mux Demux
Features
Low Insertion Loss
Wide pass band
High Channel Isolation
High Stability and reliability
Applications
Channel Add/Drop
DWDM Network
Fiber Optical Amplifier
Performance Specifications
Parameter | 4 Channel | 8 Channel | 16 Channel | ||||
Mux | Demux | Mux | Demux | Mux | Demux | ||
Channel Wavelength(nm) | ITU 100 GHz Grid | ||||||
Center wavelength Accuracy(nm) | ±0.05 | ||||||
Channel Spacing (GHz) | 100 | ||||||
Channel Passband (@-0.5dB bandwidth) (nm) | ≥0.22 | ||||||
Insertion Loss(dB) | ≤1.6 | ≤2.5 | ≤3.5 | ||||
Channel Uniformity(dB) | ≤0.6 | ≤1.0 | ≤1.5 | ||||
Channel Ripple(dB) | 0.3 | 0.3 | 0.3 | ||||
Isolation(dB) | Adjacent | N/A | >30 | N/A | >30 | N/A | >30 |
Non-adjacent | N/A | >40 | N/A | >40 | N/A | >40 | |
Insertion Loss Temperature Sensitivity(dB/℃) | ≤0.005 | ||||||
Wavelength Temperature Shifting(nm/℃) | <0.002 | ||||||
Polarization Dependent Loss(dB) | <0.1 | ||||||
Polarization Mode Dispersion(PS) | <0.1 | ||||||
Directivity(dB) | >50 | ||||||
Return Loss(dB) | >45 | ||||||
Maximum Power Handling(mW) | 500 | ||||||
Operating Temperature(℃) | -5~+75 | ||||||
Storage Temperature(℃) | -40~85 | ||||||
Package dimension(mm) |
| ||||||
Above specification are for device without connector
Order Information
Configuration | Channel No. | Channel | Pigtail Type | Fiber length | Dimensio(mm) | Connector |
M=Mux D=Demux | 04=4 Channel 08=8 Channel 16=16 Channel
N=N Channel …… | C20= 1561.42 nm …… | 0=250um 1=900um 2=2.0mm | 1=1m | 1= L100 x W80 xH10 2=L140xW100xH15 3=19 1U Rack | 0=None 5=others |
