2x2 mini abs box quick single mode optical coupler splitter fbt fiber optic coupler
- Shenzhen
- T/T Credit Card
You May Like
-
Hot sales Wholsales OEM factory fiber optic plc splitter steel fiber optic splitter PLC 1x4 plc splitter
-
3 fibers 1310nm Optical circulator for edfa and amplifier
-
3 port 1310nm Optical Circulator with connector FC/UPC
-
980nm, 1064nm, 1310nm, 1550nm,1x2 or 2x2 signal mode Fiber Optical Circulator
-
Made in China steel tube fiber optical circulator 3 port
-
3 ports circulator for telecommunication
Product Details
| Place of Origin | Guangdong, China | Brand Name | XYT | |
| Model Number | XYT-FBT-SM-A-22 |
Product Description
2x2 mini abs box quick single mode optical coupler splitter fbt fiber optic coupler
Features
Low insertion loss and low PDL
High reliability& High stability
RoHS compliant
Applications
EDFA
CATV Passive network WAN
FTTH
Specification
Parameter | Unit | Value | ||||||
Type |
| Dual-Window Coupler(DWC) | Three-Window Coupler(TWC) | |||||
Grade |
| P | A | P | A | |||
Operating wavelength | nm | 1310 and 1550 | 1310,1490 and 1550 | |||||
Operating bandwidth | nm | 1310/1550±40 | 1310/1550±40 and 1490±10 | |||||
Insertion loss | 50/50 | dB | ≤3.6 | ≤3.8 | ≤3.6 | ≤3.8 | ||
| 40/60 | dB | ≤4.7/2.7 | ≤4.9/2.9 | ≤4.7/2.7 | ≤4.9/2.9 | ||
| 30/70 | dB | ≤6.0/1.9 | ≤6.3/2.1 | ≤6.0/1.9 | ≤6.3/2.1 | ||
| 20/80 | dB | ≤7.9/1.3 | ≤8.4/1.4 | ≤7.9/1.3 | ≤8.4/1.4 | ||
| 10/90 | dB | ≤9.20~11.00/0.75 | ≤8.80~11.40/0.8 | ≤9.20~11.00/0.75 | ≤8.80~11.40/0.8 | ||
| 5/95 | dB | ≤12.05~14.20 /0.4 | ≤11.55~14.65/0.5 | ≤12.05~14.20 /0.4 | ≤11.55~14.65/0.5 | ||
| 3/97 | dB | ≤14.10~16.50/0.35 | ≤13.60~17.05/0.45 | ≤14.10~16.50/0.35 | ≤13.60~17.05/0.45 | ||
| 2/98 | dB | ≤15.60~18.55/0.3 | ≤15.00~19.20/0.4 | ≤15.60~18.55/0.3 | ≤15.00~19.20/0.4 | ||
| 1/99 | dB | ≤18.45~21.70/0.25 | ≤17.80~22.40/0.35 | ≤18.45~21.70/0.25 | ≤17.80~22.40/0.35 | ||
Polarization Dependent Loss | dB | ≤0.15 | ≤0.2 | ≤0.15 | ≤0.2 | |||
Temperature Dependent Loss | dB | ≤0.2 | ||||||
Directivity | dB | ≥55 | ||||||
|
|
| ||||||
Return Loss | dB | ≥55 | ||||||
|
|
| ||||||
Operating Temperature | ℃ | -40~+85 | ||||||
|
|
| ||||||
Storage Temperature | ℃ | -40~+8 | ||||||
Notes:
1.The above specification is without connectors.
2.Add an additional 0.20dB loss per connector.
