5 L Bottle Machine Rotary Blow Molding Machine Cheap Mono Block Mchine
Negotiable
/ Set
1 Set(Min.Order)
- 10 Set / Sets per Month
- Huangpu
- T/T Credit Card
You May Like
-
Automatic Blow Molding Machine with CE Certificate (08XSD)
-
Rotrary Plastic Bottle Blow Molding Machine (06XST)
-
Cap Compression Molding Machine (36 Cavities, 50,000PCS/hour)
-
Cap Compression Molding Machine (24 Cavities, 22000PCS/hour)
-
Carton Forming Machine Automatic Case Forming Machine
-
High Speed Carton Sealer with Double Lanes (FX70)
Product Details
| Condition | New | Application | Bottle | |
| Plastic Processed | PET | Blow Moulding Type | Stretch Blow Moulding | |
| Automatic | Yes | Place of Origin | Guangdong, China | |
| Brand Name | VANTA | Model Number | DSL-02XST | |
| Voltage | 380V | Power(W) | 100KW | |
| Dimension(L*W*H) | 4800*2000*2800 | Weight | 6.5T | |
| Certification | CE | Warranty | 12 months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Product information
1. Description:
The DSL series of rotary blow molding machine is developed by Vanta's engineer under the world's most advanced technology of bottle making. The bottle blower is specially designed for 5L and bigger bottles. The equipment mainly consists of host machine, heating furnace, auto conveying device, electrical system, and compressed air system. The electrical and pneumatic components, sealing element, bearing, and reducer adopt imported brands to ensure high performances.
2. Equipment datasheet
| PRODUCTION DATA | Mould cavities | N | 2 | |
| Max. body diameter | mm | 210 | ||
| Max. Height | mm | 430 | ||
| Max. diameter | mm | 45 | ||
| Max. preform Height | mm | 195 | ||
| Max. capacity | ml | 5000 | ||
| Max. output for 500ml , bottle (*) | pcs/h | 1500 | ||
| Nominal output for 500ml , bottle (*) | pcs/h | 1200 | ||
| Rate of finished product(*) | % | ≥99.5 | ||
| DIMENSION | Length *Width*Height | mm | 4800*2000*2800 | |
| ELECTRICAL FEEDING | Voltage | V | 380 | |
| Total power installed | kW | 100 | ||
| Medium power absorbed | kW | 25 | ||
3. Advantages:
3.1 High productivity
3.2 Specially designed for 5L and bigger bottle
3.3 Only need to use high pressure air, save cost
3.4 High degree of automation and intelligence
3.5 Good, stable product quality
3.6 Low noise
3.7 High cleanliness, without pollution
3.8 Low cost of production
3.9 Low failure rate
4. Product:
