scve tubular motor best quality uses shutter roller doors SF92 M2 3

FOB Price

USD $92 - $106 / Piece

50 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	SCVE	Model Number	SF92 M2 3
Type	Other, AC MOTOR	Frequency	50Hz
Output Power	580W-910W	Protect Feature	Explosion-proof
Phase	Single-phase	Certification	CCC, CE, ROHS, UL, Other, CCC, CE, ROHS, UL, TUV
AC Voltage	208-230 / 240 V	Place of Origin	Zhejiang, China
Efficiency	IE 4

scve tubular motor best quality uses shutter roller doors SF92 M2 3
1 Best quality in China
2 Diameter 92MM
3 230V/50Hz

Detailed Product Description

1:230Volt/50Hz
2:Big motor: 140Nm -330Nm
3:Used to factory door , big door.
4:Best quality in China

92mm tubular motor
1:Best price and with competitive price
2:Excellent appearence without manual
3:230V/60Hz
4:Rodio control

5:5 years warranty

6:TUV,CCC,ROSH,CE,UL,ISO9001 Certificate

92mm Diameter Tubular Motor specification
	Model	(Nm)	(Rpm)	(V)	(Hz)	(W)	(A)	(Kg)
1	SF92-N-140M	140	12	230	50	580	2.6	13.5
2	SF92-N-180M	180	12	230	50	626	2.8	13.5
3	SF92-N-230M	230	12	230	50	830	3.6	13.5
4	SF92-N-250M	250	8	230	50	850	3.9	14.6
5	SF92-N-280M	280	8	230	50	778	4.1	14.6
6	SF92-N-300M	300	8	230	50	880	3.5	14.6
7	SF92-N-330M	330	8	230	50	908	4.0	14.6
