scve tubular motor best quality uses shutter roller doors SF92 M2 AC tubular motor

FOB Price

USD $92 - $106 / Piece

10 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	SCVE	Model Number	SF92 M2
Type	Asynchronous Motor	Frequency	50Hz
Output Power	580W-910W	Protect Feature	Explosion-proof
Phase	Single-phase	Certification	CCC, CE, ROHS, UL, Other, CCC, CE, ROHS, UL, TUV
AC Voltage	208-230 / 240 V	Place of Origin	Zhejiang, China
Efficiency	IE 4

ac tubular motor
1 Best quality in China
2 Diameter 92MM
3 230V/50Hz

Detailed Product Description

1:230Volt/50Hz
2:Big motor: 140Nm -330Nm
3:Used to factory door , big door.
4:Best quality in China

Detail specification:

92mm tubular motor
1:Best price and with competitive price
2:Excellent appearence without manual
3:230V/60Hz
4:Rodio control

5:5 years warranty

6:TUV,CCC,ROSH,CE,UL,ISO9001 Certificate

92mm Diameter Tubular Motor specification
	Model	(Nm)	(Rpm)	(V)	(Hz)	(W)	(A)	(Kg)
1	SF92-N-140M	140	12	230	50	580	2.6	13.5
2	SF92-N-180M	180	12	230	50	626	2.8	13.5
3	SF92-N-230M	230	12	230	50	830	3.6	13.5
4	SF92-N-250M	250	8	230	50	850	3.9	14.6
5	SF92-N-280M	280	8	230	50	778	4.1	14.6
6	SF92-N-300M	300	8	230	50	880	3.5	14.6
7	SF92-N-330M	330	8	230	50	908	4.0	14.6
