hidden roof panel roll forming machine
- 20 Set / Sets per Month
- tianjin port
- T/T
You May Like
Product Details
| Place of Origin | Hebei, China | Brand Name | jinchengxin | |
| Model Number | JCX-JCH--H |
Product Description
Specifications
Hidden roof panel roll forming machine:1.favorable price;
2. easy to operate ;
3.hight quality;
4.long service time.
Hidden roof panel roll forming machine:
The device uses a high level of automation software, production information management; the entire unit automatic control system uses highly integrated network, the automatic system performance, superior; the color-coated steel tile equipment, also has the operation, maintenance, maintenance and mechanical commissioning, Die replacement easy and so on.
Main technical parameters:
1. Passive leak: manual up tight, passive leak
2. Leak rack load: 5T
3. Rack: Using 500H steel welding.
4. Forming Machine-driven feeding frame Type: Roller-type
5. Forming Machine Type: Bearing-watt box chain drive
6. Shaft Diameter: 72 mm solid shaft
7. Chain: 1.-Inch single-row
8. Molding Motor Power: 4KW cycloid reducer
9. Forming Machine speed :8-10m / min
10. Forming Machine Road Number: 20
11. Roll Material: high quality 45 # steel Duan playing pieces
12. Hydraulic station motor: 3kw
13. Hydraulic Pump Station: Gear pump
14. Cutting method: hydraulic shear
15. Scissors film forming material: Cr12
16. Shearing blade Heat treatment: HRC58 ° -60 °
17. Rolling thickness :0.5-0 .8 mm
18. Material Expand Width: 1000mm
19. Length Length Accuracy: ± 2mm
20. The computer use of PLC.
21. Computer Operator panel text screen
