JCX Downspout Elbow Machine

4kw downspout roll forming machine with bender,downspout roll forming machine,downspout machine

Details of downspout roll forming machine as follows:

1. General performance of the line

Pipe forming part:

1) Decoiler: Expansion type,max ,loading1-2T

2). Roller station:24 stations,three-dimensional correction

3). Material of mould :45# forge steel ,finish machining and plated with hard chromium

4). Diameter of the roller: Φ62mm,formed by the modulation finishing

5). The frame of the machine is 350 H steel ,the side board is made of 16mm steel structure

6). Main power:4 kW(2sets) cycloidal needle wheel type motor, birdirectional drive ( P=25.4 )

7). Cutting-to-length system:using flying saw cutting

8). Size of the main machine :11.8*1.2*0.9m(divided into two stages)

Pipe Bending Part:

1). Wall panel:22mm steel welding

2).Power::3kw

3).Driving method: two rows of 1 inch chain.

4).Operational principle:Rack mechanical driving

5).Control method: PLC

6).Apperanace size:1.2*1.5*0.8m

2. Working flow

1) Decoiling: feeding of the material for bottom metal strip.

2) Roll forming: producing the bottom metal strip for roof or wall panel.

3) Raw material feeding table: In order to feeding the mmaterial straightly.

4) Main forming station: shaft material is 45# steel forged,roller material is 45# bearing steel.

5) Cutting system: fly saw cutting system

6) Controlling system: All the production line will controlled by the PLC,realized the full- automatic.

7) The counter: every machine we will provided several extra counters for the damage of the counter.

8) Run-out table:we have different kinds of receiving table,the simple one,the auto-stacker or other designed run out table,we can designed it according your demand.

9) Pipe Bending Part.

10) We will provided a whole production line if you have no special requests.
