HDMI matrix

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Odin		Model Number	DC-MAX9632-A
Place of Origin	Jiangsu, China

HDMI matrix
1.Support multiple video signal input and output;
2.Power-off Memorizing Function supported.

video wall matrix
1.Support multiple video signal input and output;
2.Power-off Memorizing Function supported.

Specification

	Classify	Parameter
INPUT	Port	Standard HDMI 1.3 Port
	Resolution	1920*1200@60Hz
	EDID	Odin Standard Digital EDID
	Bandwidth	Unipath 2.25G
	Indicator light	1 Light/Unipath
OUTPUT	Port	Standard HDMI 1.3 Port
	Resolution	1920*1200@60Hz
	Bandwidth	Unipath 2.25G
CONTROL	Input	Standard RS232
	Output	Standard RS232
	Keyboard	None
	Software	MagicTunningSoftware
	Switch Time	<1S
	Plan	Max 10 Groups
OTHER	Power	220VAC/50Hz
	Consumption	15W
	Working Temperature	0°C~+55°C
	Storage Temperature	10%~90%
	Size	482mm x220mm x 44.45mm(LxWxH19”1U)
	Weight	2.5Kg
	Installation	Cabinets or Desktop installation
	Shock Resistance	1.2M HIGH
	ESD	8KVDC
