Teka Concrete Mixer Motor model TPZ500G
USD $1 - $1,000,000
/ Unit
1 Unit(Min.Order)
- 6 Unit / Units per Month
- Shanghai
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Jiangsu, China | |
| Brand Name | Teka | Model Number | TPZ500G | |
| Motor Power | 22KW | Mixing Power | 22KW | |
| Charging Capacity | 800KG/500L | Reclaiming capacity | 0.33cbm | |
| Speed of Mixing Drum | 15 | Water Supply Mode | automatic | |
| Working Cycle Period | 28/hour | Discharge Way | Hydraulic | |
| Outline Dimension | 1712mm*1712mm*2100mm | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Product Description
Teka Concrete Mixer Motor Model TPZ500G
| Model No. | TPZ500G |
| Filling quantity mixer | 500 Liters |
| Filling quantity mixer | 800 Kgs |
| Compacted concrete output cycle | 0.33 M3 |
| Electric motor-mixer output | 22 KW |
| Hydraulic drive motor discharge | 1.1 KW |
| Mixing star | 1 Qty |
| Mixing paddles per mixing star | 3 Qty |
| Side scraper / Discharge scraper | 1/1 |
| Speed of rotor | 15 Upm |
| Speed of mixing star | 42 Rpm |
| Total diameter of mixer | 1712 ¢ |
| Total height of mixer | 2100 mm |
| Weight of mixer | 3100 Kgs |
| Filling capacity of skip hoist bucket | 750 Kgs |
| Electric motor-skip hoist | 5.5 Kw |
| Speed of bucket | 0.33 M/sec |
| Weight of bucket | 800 Kgs |
Outline Dimension
Products advantages:
- Suitable for a wide range of mixing applications
- Large installed base of thousands of machines worldwide
- Exceptional reliability
- Perfect for retrofitting thanks to compact size
- Intelligent component layout simplifies maintenance
Application fields:
Packaging & Shipping
Company Information
Teka Machinery (Taicang) Co., Ltid. is a branch company of Teka Germany. We started from 2005, It is about 10 years already since we came to China.
Established in 1961, TEKA Maschinenbau GmbH has become one of the leading manufacturers of high-performance mixers and mixing plants for the building-materials industry. With an installed base of more than 18,000 mixers and thousands of mixing plants, it’s clear that Teka products are well accepted and highly regarded – and versatile enough for many different applications.
Interested in our products, contact us for quote now!
