Home > Products > Optic components > Fiber Optical OM3 MPO Cassette /MTP - LC 12F OM3 Cassette
Fiber Optical OM3 MPO Cassette /MTP - LC 12F OM3 Cassette
- 3000 Piece / Pieces per Month
- FOBSZ
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | HILINK | |
| Model Number | HL-MTP-MO3 |
Product Description
Fiber Optical OM3 MPO Cassette /MTP - LC 12F OM3 Cassette
- Module optical fiber connections to the torsion of the sequence
- Can provide data center and SAN System, simple and flexible
- MPO trunk connector fixed on the back of module
- The standard 19" can be installed on any cabinet
- Convient to be installed, moved and added
Main application :
Datacenter rack mount patch panel
Connection between trunk cables to patch cords
Connector requirement
| Multi Mode | Single Mode | ||
| IL | MPO | Single max :0.35db (L) Single Max : 0.60db (G) | Single max :0.35db (L) Single max :0.75db (G) |
| LC | MAX :0.10dB(L) MAX :0.15 db (G) | max :0.30db | |
| RL | MPO | >20DB | >60DB (8 degree Angle Polish ) |
| LC | >30db | >50 db (UPC) >60DB(APC) | |
| Mechanical | MPO | <0.2DB, 200 times insertion | |
| LC | <0.2db, 500times intertion | ||
| Working Temp | -20~ +60 'C | ||
| Enviromental | Storage Temp | -40~ + 70'C | |
| Install Temp | -5~ + 50'C | |
OM3/OM4 fiber cable, plus the connectors from US Connector
All the production is done in hilink factory facility to ensure the system performance and quality.
Modular and snapping fit design, which offer great convenience to installers at the site for installations as well as
OEM and ODM
OEM/ODM order is available
Shipment
International Express: DHL, FedEx,EMS,TNT, UPS and so on. It takes 3-7 days.
Guarantee
We promise all the advertised optical modules are brand new and absolutely never use old and refurbished materials. All the optical modules have been through functional test and aging test. We provide 3 years warranty for all the optical transceivers from the date of shipment.
What we supply
We supply wide range of high quality optical transceiver modules and passive CWDM/DWDM Mux/Demux. Our products are compatible with Cisco, Huawei, Extreme, HP, Finisar, Broadcom, Foundry, Alcatel, D-link, Enterasys, Netgear, Juniper, Nortel, Linksys, Allied, Zyxel, Dell, Redback, H3C, ZTE, Ruijie, Ciena , Alcatel-lucent, etc.
If you can't find your interested product information here, can send us inquiry to get detail specification and we will follow-up timely.
