Dual SC Fast Eehernet 100base Media Converter Support SNMP
- Shen Zhen
 - T/T Credit Card

You May Like
-


SC Single Fiber Media Converter 10/100Base Equipment
 -


SFP LC Media Converter 10/100Base China Supplier
 -


China Supplier Media Converter 10/100Base Optical
 -


Media Converter 10/100Base Module China Supplier
 -


Media Converter Single Fiber FC RJ45 10/100Base Module
 -


Dual Fiber FC RJ45 Connector Media Converter 10/100Base

Product Details
| Place of Origin | Guangdong, China | Brand Name | HaiLi | |
| Model Number | HL- media converter |
Product Description
Specifications
Fast Eehernet 100base Media Converter Support SNMP1. 10/100Mbps RJ45 port
2. SC,single mode
3. Transmission 20/40/60/80km
Dual SC Fast Eehernet 100base Media Converter Support SNMP
100base Media Converter
Feature
n Built-in IP-based Web Interface.
n Supporting remote and local management.
n Supporting IEEEE 802.3X Frame Flow Control for Full-Duplex mode.
n Store and Forward mechanism.
n Manual IP address setting/DHCP client for IP address assignment.
n SNMP v1 / v2c monitor / private Enterprise MIB.
n Event trap and SNMP trap support.
n Speed duplex mode configuration / Flow Control setting / bandwidth Control on TP / Fiber port.
n Supports Port Status / Ethernet Statistics on both TP and Fiber interface.
n Supports Maximum frame size to 16K bytes.
n Loop detection / Broadcast / Multicast / Unicast storm control.
n Management VLAN / 16 IEEE 802.1Q VLAN groups / Q-in-Q VLAN.
n 802.1p Tag Priority / IP address priority / IP DSCP option in.
n Quality of Service Mode and Strict Priority / Weighted Round Robin (WRR) QoS policies.
n TS-1000 OAM / IEEE 802.3ah OAM / Loop Back Test.
n 16 TCP / UDP Filter groups.
n Password setting, IP setting and devices description setting through Planet Smart discovery utility.
n Firmware upgrade via remote Web interface.
n LED indicators for easy network diagnosing.
n Reset Button at the front panel for the factory default reset.
n Choice of fiber-connector from SC, LC, WDM, multi-mode / single-mode fiber /1000Base-SX / LX mini GBIC module
Specification
parameter  | Specifications  |
Access mode  | 10/100/1000Mbps Gigabit Ethernet  |
Standard  | IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX/FX Fast Ethernet, IEEE802.3ab 1000Base-T , IEEE802.3z 1000Base-SX/LX Gigabit thernet,IEEE802.1qVLAN,IEEE802.1p QoS,IEEE802.1d Spanning Tree  |
Wavelength  | 850nm/1310nm/1550nm  |
Transmission distance  | multi-mode Dual-fiber: 220m (62.5/125um)/550m (50/125um) single mode Dual-fiber: 20/40/60/80 Km single mode Single fiber: 20/40/60/80 Km Category-5 twisted pairs: 100m  |
Port  | One RJ45 port:   Connecting with STP/UTP category-5 twisted pairs One optical port:   Multi-mode Dual-fiber: SC (50, 62.5/125um) Single mode Dual-fiber: SC/FC (9/125um) Single mode Single fiber: SC/FC (9/125um)  |
Conversion means  | Media conversion  |
Delay  | <10us  |
BER  | <10-9  |
MTBF  | 100,000 hours  |
LED indicator  | PWR ,100M;FXL,1000M,TX,RX;  |
Power supply  | AC220 0.5A/DC-48 (built-in)  |
Power consumption  | 5W  |
Operating temperature  | -10~55°C  |
Operating humidity  | 5%~90%  |
Storage temperature  | -40~70°C  |
Maintaining humidity  | 5% ~ 90% non-condensing  |
Dimensions  | 95mm*70mm*25mm(external power supply)  |
Picture show
Media converter

FAQ
Q:Do you sell second-hand products?
A:No.All our products are brand new,we never use secont-hand components.
Q:What payment terms do you accept?
A:T/T,Paypal,Western Union are acceptable.
Q:What are the shipping ways can you offer?
A:Our usual shipping ways are DHL,FedEX,TNT,UPS,EMS etc.It will take 3-7days.
Q:Do your products come with warranty?
A:Yes,We provide 3 years warranty for all our products from the date of shipment.
Q:What devices can your products compatible with?
A:Our products are compatible with Cisco,Huawei, Ciena, H3C, HP, Extreme, Foundry, Brocade, D-link, Alcatel, Riverstone, Enterasys, Netgear, Nortel, Juniper, Ruijie, Zyxel, etc.
Q:How to place an order?
A:1>Order details confirmed,please tell us the model and quantity you need.
    2>Proforma Invoice confirmed, the order will be arranged upon receipt of your payment.
    3>Confirm and ship the goods, then tracking number will be sent to you promptly.
    4>We will help to track your goods until you receive them safely.
As we have various kinds of products,if you can't find the correct item,please send us inquiry.We will follow up shortly.
