Home > Products > Steel Valve > Stainless Steel Ball Valve With Locking Handle
Stainless Steel Ball Valve With Locking Handle
- QINGDAO/TIANJIN/SHANGHAI
- T/T
You May Like
Product Details
| Standard or Nonstandard | Standard | Structure | Ball | |
| Pressure | Other, Medium Pressure, Medium Pressure | Power | Manual | |
| Material | Other, Casting, stainless steel, carbon steel | Temperature of Media | Normal Temperature | |
| Media | Other, Water, Oil,Water,Gas | Port Size | 1/4''-4'' | |
| Place of Origin | Shandong, China | Application | General |
Product Description
Stainless steel ball valve with locking handle:
Product Description:
| Standard: | ANSI, DIN, JIS, BS | ||||
| Size: | 2"-32" or DN50-DN800 | ||||
| Pressure: | Class150-1500LB or PN16-PN160 or 10K-40K | ||||
| Design & Manufacture Std: | API608, ASME B16.34, API6D, BS5351,DIN,JIS | ||||
| Face to Face Std: | ASMEB16.10 (JISB2002),API 6D, DIN3202, ASME B16.25 | ||||
| End Connection Std: | ASME B16.5,ASME B16.47, JISB2212-JISB2214, DIN2543-2550,ASME B16.34 | ||||
| Structure Type: | One-piece, Two-piece, Three-Piece,Reduced bore, Full bore Floating type(1/2 -10 ), trunnion type(2 -32 ) | ||||
| Operated way: | Lever, Gear, Pneumatic, Electric Acturtor | ||||
Product picture:
Packaging & Shipping:
Packaging Detail: pallet, wooden case, or as customers' requirment
Delivery Detail:about 30-35days after get the payment
Company Information:
BESTFLOW INDUSTRIAL CO., LTD. is one of professional manufacturers and exporters of
pipeline fittings in China. The products includes: steel fittings, steel flanges, steel nipples &
couplings, iron fittings etc., they are widely used the pipe systems of nuclear power plants,
power station, water, natural gas, petrochemical, oilfields, fire-fighting, ship buildings,
engineering fields and construction industry.
Warmly welcome the customers in domestic and foreign countries visit us, “BESTFLOW”
products would like to create the Brilliant future together with you.
