Home > Products > solar battery > 12v 100ah Exide Battery Lead Acid Battery for Solar Power System

12v 100ah Exide Battery Lead Acid Battery for Solar Power System

FOB Price

US$ 1 - 200 / Piece

50 Pieces(Min. Order)

Port Guangzhou
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	China	Brand Name	Fortune Power, Fortune Power Battery
Model Number	NP12-100	Usage	Other, UPS, UPS/Solar/Wind/Alarm/Security/Telecom/Emergency Light System Etc
Voltage	Other, 12v	Sealed Type	Sealed
Maintenance Type	Free	Size	407174232mm
Weight	30KG	Nominal Capacity	100AH

Product Description

Specifications Of china battery manufacturer agm gel battery solar battery 12v100ah :
Nominal Voltage		12V
Rated Capacity (10 hour rate)		100AH
Size (LengthWidthHeight*Total Height)		406173210*230MM
Weight Approx		29.8KG
Capacity 25°C (77°F)	10 Hour Rate(9.0A)	100AH
	5 Hour Rate(14.4A)	80AH
	1 Hour Rate(54.0A)	60AH
	1.5 Hour Discharge To 10.5V	40A
Internal Resistance	Full Charged Battery at 25°C(77°F)	5mΩ
Capacity Affected By Temperature (10 Hour Rate)	40°C(104°F)	102%
	25°C(77°F)	100%
	0°C(32°F)	85%
	-15°C(5°F)	65%
Self-Discharge at 25°C (77°F)	Capacity after 3 Month Storage	91%
	Capacity after 6 Month Storage	82%
	Capacity after 12 Month Storage	64%
Terminal		T16
Cycle Charge (Constant Voltage)	Initial Charging Current Less Than 40A
	Voltage 14.40-14.80V Time 14~16h
Float Charge (Constant Voltage)	Voltage 13.50-13.80V
Warranty	2 Years
OEM Service	Accept
Color	Black, Gray
Certificate	CE; UL; ISO9001; ISO14001; TLC; Solar Product Certificate

Our Material Advantage:

1) Container/Cover: Made of UL94HB and UL 94-0ABS Plastic.
2) Negative Plates: Use the special PbCa alloy grids, optimize the recombination efficiency and less gassing.
3) High quality AGM separator
4) Positive plates: PbCa grids minimize corrosion and prolong life.
5) Terminal post: Copper or lead material with maximum conductivity, enhance the high current rapidly.
6) Vent Valve: Allows the release of the excess gas automatically for safety.

Fortune Power Battery Production Progress

Product Application

Mainly applied for:

1.Solar power system(off-grid solar power system, solar street light system, solar garden light system)

2.Wind Power System

2. UPS and computer backup power

3. telecommunication system

4. Power station System

5. Railway System

6. Emergency lighting system

7. Automatic control system

8. Alarm system for fire protection, security

Storage and installation:

1.Fortune Power battery is not in use should remove the cable, pole jacket cover and wipe clean;

2.once every three months for Fortune Power battery to maintain charging, constant voltage charging method for limiting law, the initial charging current is 0.1CA, the charging voltage is 2.4V / single cell (25 ℃ when);
3.Fortune Power battery should be stored in dry and ventilated place, away from direct sunlight and away from heat sources;
4.when handling batteries even force, the force of the housing portion of the battery to avoid damage to the pole;
5.the installation should use insulated tools to prevent click.

Solar Battery Types

Battery Type	Nominal Voltage(V)	10h rate capacity(ah)	dimension				Weight(kg)
Battery Type	Nominal Voltage(V)	10h rate capacity(ah)	Length	Width	Height	Total height	Weight(kg)
12-17	12	17	181	76	167	167	5.5
12-24	12	24	166	125	175	125	8.5
12-38	12	38	198	166	175	175	13
12-65	12	65	350	166	175	175	21
12-80	12	90	330	172	238	240	27
12-100	12	100	405	175	230	230	30
12-120	12	120	405	175	230	230	31
12-150	12	150	483	170	239	239	42
12-200	12	200	522	240	242	242	55

Fortune Power Battery Factory Informations

Fortune Power Battery Certificates

FAQ

Q1. Are you the manufacturer?

Yes, we are the leading manufacturers in Guangzhou.

Q2. What kinds of battery do you have?

We have AGM Battery, GEL Battery, UPS Battery, Solar Battery, Lead Acid Battery…

Q3. What is your product series range?

12V 1.2Ah-250Ah

6V 1.2Ah-220Ah

2V 100Ah-3000Ah

Q5.What is your products advantage?

We produce lead plates by ourselves, we control the quality strictly. Offer you excellent quality with reasonable price and good service.

Q6. What is your battery life cycle?

Life cycle is connecting with discharge depth of discharge(DOD)

If 30% DOD,1500 cycle times,

If 50% DOD,700 cycle times,

If 100% DOD,300 cycle times.

Q7.How about the warranty of your products?

3 years warranty since shipping day.

Q8.Do you offer samples for testing?

Yes, we offer free samples for testing, but the clients need pay the freight.

Q9.Is it available for OEM service?

Yes, registered brands from reliable client are available.

Q10.What certificates do you have?

We have CE,ISO,SGS,UL,CQC certificates.
