WEICHAI motor diesel barco for sale
- 6000 Set / Sets per Month
- Qingdao China
- T/T Credit Card
You May Like
Product Details
| Condition | New | Engine | 4 Stroke | |
| Engine Capacity | 4.1 - 5L | Fuel Type | Diesel | |
| Cylinders | 4 | Engine Position | Inboard | |
| Dimensions (L x W x H) (mm) | 1065*744*856 |
Product Description
Main technical data of motor diesel barco
Model of engine | motor diesel barco D226B-3C1 |
Rated power(HP) | 48HP |
Speed(rpm) | 1800 |
Type | Four stroke, water cooled, in-line, wet cylinder liner |
Number and layout of cylinders | 3 cylinders, |
Bore(mm) | 105 |
Stroke(mm) | 120 |
Total displacement | 3.12L |
Fuel consumption | 198 g/kW.h |
Specific oil consumption | 1.0 g/kW.h |
Direction of rotation (facing to end) | Clockwise |
Emission standards: | IMO TIER II |
Noise: | <105dB(A) |
Starting way: electric starter | Electric starter |
Idle speed (R/MIN) : | 650±30 |
The smoke (Rb) | < 2.0 |
Overall dimension L×B×H(mm) | 1065*856*744 |
Reference picture of motor diesel barco :
motor diesel barco overall dimensions
Motor diesel barco Details Display
(1)Engine Block (2) Cylinder Head (3) Crankshaft
(4) Flywheel (5)Front and Rear Cover (6)Other Casting Parts
Accessaries
a.Flywheel shell: SAE 1;
b.Pulley: different number of reserved slots (4,6), can bring flange;
c.Start Mode: electric start/gas start/electric and gas dual-start(optional);
d.Governor: Mechanical governor;
e.Fuel stop solenoid valve: Optional
f.Parking electromagnet: Optional
g.Sea water pump: Optional
h.Remote meter and transmission lines:Optional . remote control devices /remote display devices,
different lengths of transmission line.
1. Q: What rated power(kW/HP) you need?
