Weichai Deutz TD226B-3C small Schiffsmotor for boat
- 6000 Set / Sets per Month
- Qingdao Port
- T/T
You May Like
-
Deutz diesel inboard engine and gearbox for boat usage
-
Weichai Deutz TD226B-3C marine engine with CCS
-
Deutz TD226B-3C marine diesel engine
-
Deutz TD226B-3C 40KW 1500rpm merine diesel engine for sale
-
Deutz TD226B-3C 40KW 1500rpm marine diesel engine for boat
-
GOOD QUANLITY ! Weichai X6170ZC series 6 cylinder marine inboard engine for sales in China
Product Details
| Condition | New | Engine | 4 Stroke | |
| Fuel Type | Diesel | |||
| Cylinders | 3 | Engine Position | Inboard | |
| Dimensions (L x W x H) (mm) | 890*550*1060mm |
Product Description
226B Series Schiffsmotor | ||||||
Type | Cylinder-numbers | Rated Output(kW) | Rated speed(R/min) | Starting method | Net weight(Kg) | Suit for application |
TD226B-3C | 3 | 40 | 1500 | Electrical | 560 | fishing ship, transport ship |
TD226B-3C1 | 3 | 50 | 1800 | Electrical | 560 | fishing ship, transport ship |
TD226B-3C2 | 3 | 55 | 2100 | Electrical | 560 | fishing ship, transport ship,speed boat |
TD226B-3C3 | 3 | 60 | 2500 | Electrical | 560 | transport ship,speed boat |
TD226B-4C | 4 | 60 | 1500 | Electrical | 650 | fishing ship, transport ship |
TD226B-4C1 | 4 | 70 | 1800 | Electrical | 650 | fishing ship, transport ship |
TD226B-4C2 | 4 | 75 | 2100 | Electrical | 650 | fishing ship, transport ship,speed boat |
TD226B-4C3 | 4 | 80 | 2500 | Electrical | 650 | transport ship,speed boat |
TD226B-6C | 6 | 90 | 1500 | Electrical | 760 | fishing ship, transport ship |
TD226B-6C1 | 6 | 105 | 1800 | Electrical | 760 | fishing ship, transport ship |
TD226B-6C2 | 6 | 115 | 2100 | Electrical | 760 | fishing ship, transport ship,speed boat |
TD226B-6C3 | 6 | 120 | 2500 | Electrical | 760 | transport ship,speed boat |
TBD226B-6C | 6 | 110 | 1500 | Electrical | 810 | fishing ship, transport ship |
TBD226B-6C3 | 6 | 120 | 1800 | Electrical | 810 | fishing ship, transport ship |
TBD226B-6C4 | 6 | 135 | 2100 | Electrical | 810 | fishing ship, transport ship,speed boat |
TBD226B-6C5 | 6 | 150 | 2500 | Electrical | 810 | transport ship,speed boat |
| Type | Water cooled, inline, 4-strike, natural aspiration, turocharged, turbocharged and intercooled |
| Num.of cylinders | 3/4/6 |
| Bore/Stroke(mm) | 105/120 |
| Displacement(L) | 3.12/4.16/6.23 |
| Min.Fuel consumption(g/kw.h) | ≤198 |
| Min.oil consumption(g/kw.h) | ≤1.36 |
| idle speed(r/min) | 600±50 |
| Average noise dB(A) | ≤100 |
| Steady gorenor radio | ≤8% |
| Firing Sequence | 1-3-2/1-3-2-4/1-5-3-6-2-4 |
| Starting method | Electricity |
| Cooling method | Water cooling forced circulation |
| Lubricating method | Pressure lubricating |
| Lub.oil volume(L) | 15 ( 6-cylinder) |
| Crankshaft rotation direction | anti-clockwised |
