SHR Series High-speed Plastic Mixer/plastic Mixing Machines
- SHANGHAI
- T/T Credit Card
You May Like
Product Details
| Condition | New | Application | plastic powder granulator mixing | |
| Automatic Grade | Automatic | Place of Origin | Jiangsu, China | |
| Brand Name | Friend | Model Number | SHR | |
| Certification | ISO9001 | Warranty | 1 YEAR | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
SHR series high-speed plastic mixer/plastic mixing machines1. Mixing and drying of all kinds of plastic materials
2. CE
SHR series high-speed plastic mixer/plastic mixing machines
(1) It is used in mixing, drying, colouring and other technique of all kinds of plastics.
(2) Its heating mixing has self-friction, electric heating and steam heating modes.
(3) Two layers of sealing is adopted in the pot cover.
(4) It is equipped with the pulse dusting device.
(5) The blades have passed the test of dynamic balance and static equilibrium.
The main technical parameters
Technical Specification
Model | Total Cubage(L) | Effective Cubage (L) | Motor Power (KW) | Rotate Speed (RPM) | Heating Method | discharging method |
SHR-5A | 5 | 3 | 1.1/1.5 | 700/1400 | Self-friction | Manual |
SHR-10A | 10 | 7 | 2/2.4 | 1000/2000 | ||
SHR-25A | 25 | 20 | 3/5.5 | 720/1440 | ||
SHR-50A | 50 | 35 | 7/11 | 500 | electricity or steam | Pneumatic/Manual |
SHR-100A | 100 | 75 | 14/22 | 650/1300 | ||
SHR-200A | 200 | 150 | 30/42 | 475/950 | ||
SHR-600A | 300 | 225 | 40/55 | 475/950 | ||
SHR-500A | 500 | 375 | 47/67 | 430/860 | ||
SHR-800A | 800 | 600 | 60/90 | 370/740 | ||
SHR-1000A | 1000 | 750 | 83/110 | 350/700 | Self-friction | Pneumatic/Manual |
SHR-200C | 200 | 150 | 30/42 | 650/1300 | ||
SHR-300C | 300 | 225 | 40/55 | 600/1200 | ||
SHR-500C | 500 | 375 | 47/67 | 500/1000 |
