Home > Products > Photoelectric sensors > U Shape Photo Sensors Switches, 7mm or 30mm slot width, Fork sensors, Connector type offered

U Shape Photo Sensors Switches, 7mm or 30mm slot width, Fork sensors, Connector type offered

FOB Price

USD $20 - $30 / Piece

10 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

PS. These sensors can be connector type which with 150mm cable, cable type with 2m cable.

Product Description

Emitting light	Red LED:630nm
Operating voltage	DC:10~30VDC±10%(Ripple P-P:10%Max)
Current consumption	15mA Max
Load current	100mA Max at DC 24V
Output type	N=NPN.NO P=PNP.NPN
Protection circuit	Reversed supply ciruit protection,short citcuit protection output
Response time	0.3 ms Max
Insulation resistance	20M Ωmin.(DC500V)
Voltage withstandatility	AC1000V 60Hz for 60 Sec
Operating temperature	-10°C~+45°C No freezing allowed
Ambient hunidity	35%~95%RH
Storage temperarure	-10°C~+55°C No freezing allowed
Storage hunidity	35%~95%RH
Material	ABS
Wiring method	φ2.6×2M/4-wires /φ4.2×2M/3-wires /φ4.2×2M/4-wires
Protection degree	IP66
Weight	Approx.18.5g

Diagram
