HDMI TO SDI+SDI Converter HD-SDI/3G SDI ,SDI Converter With Iron Housing
- Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Shenzhen Factory SDI to SDI VGA Converter With Audio Mini Size SDI Scaler Converter 1080p
-
Retailer SDI Signal to SDI Converter 1080p With 3.5mm Small Size SDI Scaler Converter
-
Wholesale SDI Signal to SDI Converter 1080p With 3.5mm Small Size SDI Scaler Converter
-
Professional Manufacture SDI to VGA Converter With 3.5mm Mini Size SDI Scaler Converter 1080p
-
New Model HD SDI to SDI VGA Converter With 3.5mm Stereo 1080P With ABS Shell
-
SDI to SDI + VGA With 3.5mm Converter 1080P SDI Input Output Converter Box With VGA and Audio
Product Details
| Brand Name | Protech | Model Number | PETHS | |
| Place of Origin | Guangdong, China |
Product Description
HDMI TO SDI+SDI Converter HD-SDI/3G SDI ,SDI Converter with Iron Housing
The HDMI to dual SDI converter enables you to turn your HDMI audio/video signal into two 3G/HD/SD-SDI video outputs. The SDI video outputs can then be individually extended up to 328ft (100m) over standard coaxial cable for large scale 3G-SDI video distribution, 656ft(200m) over standard coaxial cable for large scale HD-SDI video distribution, 984 ft(300m) over standard coaxial cable for large scale SD-SDI video distribution
With dual SDI outputs, you can connect your HDMI video source to a local SDI display and output an additional SDI signal into your broadcasting equipment, providing a scalable solution for any SDI broadcasting application that requires an HDMI input.
Features:
*No need to install driver, portable, flexible, plug and play.
*Auto detect resolution of SD-SDI, HD-SDI and 3G-SDI
*Support HDMI 1.3 and HDCP 1.4.
*HDMI Input/output Resolution:
480i@60Hz,576i@50Hz,720p@50/60Hz,1080i@50/60Hz,1080p@24/25/30Hz,1080p@50/60Hz
*Support digital video formats in deep color Mode at up to 36 bits (12bits/color) and 48KHz LPCM Digital audio.
Specifications:
Input Signal | HDMI Signal x 1 |
Output Signal | SDI Signal (HD-SDI, SD-SDI and 3G-SDI) x 2 |
SDI Data Transfer Rate | 270Mb/s, 1.485Gb/s, 2.97Gb/s |
HDMI Input /Output R resolution | 480i@60Hz,576i@50Hz,720p@50/60Hz, 1080i@50/60Hz,1080p@24/25/30,1080p@50/60Hz |
Transmission Distance( via BELDEN 1694A) | 300M for SD-SDI, 200M for HD-SDI and 100M for 3G-SDI signals |
Limited Warranty | 1 Year Parts and Labor |
Operating Temperature | 0℃ to +50℃ |
Operating Humidity | 10% to 85 % RH (no condensation) |
Storage Temperature | -10℃ to +80℃ |
Storage Humidity | 5% to 90 % RH (no condensation) |
Power Supply | 5V DC |
Power Consumption (Max) | 5W |
Converter Unit Cert. | FCC,CE,RoHS |
User Manual | English Version |
