Home > Products > Hydraulic check valve > VU Type Hydraulic no Returen Check Valve
VU Type Hydraulic no Returen Check Valve
US$ 2 - 25
/ Set
50 Sets(Min. Order)
- Ningbo shanghai
- T/T
You May Like
-
AJS Safety Combination Valve for Accumulator Control Valve Stop Valve
-
AQF Safety Combination Valve for Accumulator Control Valve Stop Valve
-
CQJ Type Inflating Tool for NXQ Type Hydraulic Accumulator
-
PT Pressure Measuring Connector Test Point Measuring Coupler
-
HYDAC Type FPU Series Multi Purpose Inflating Tool
-
QXF-5 Inflating Valve M16X1.5 for NXQ Type Hydraulic Accumulator
Product Details
| Standard or Nonstandard | Standard | Structure | Check | |
| Pressure | High Pressure | Power | Hydraulic | |
| Material | Forged | Temperature of Media | Normal Temperature | |
| Media | Oil | Port Size | 1/8" 1/4" 3/8" 1/2" 3/4" 1" 1.1/4" 1.1/2" 2" | |
| Place of Origin | Zhejiang, China | Model Number | VU-G1/4 | |
| Brand Name | ZY-HYD |
Product Description
Specifications
1. non-return valve
2. reliable movement;
3. easy to use, suitable for any non-corrosive fluid;
4. burst pressure changeable
VU Hydraulic check valves
VU check valves, also named: non-return valve.
It has following characteristic:
- made from 1 pc Carton Steel, means safe and compact;
- Carbon steel poppet, heat treated and milled to fit;
- Zero leakage;
- reliable operation;
- changeable spring, flexible burst pressure;
- size ranges 1/8" to 2";
- easy to use, interchangeable with other manufacturers
Notice: please pay attention to the flow direction, when use check valves, or may cause unexpected damage.
For more details pls contact
SKYPE:huangfutony
What's app:8615867415730
Contact Us
- Fenghua Zhongya Hydraulic Pressure Set Manufacture Co., Ltd.
- Contact nameJason Herman Chat Now
- Phone86-574-88850798
- AddressNO.8 Xianghe Road,Fenghua,Ningbo,China, Ningbo, Zhejiang
