CFM-Tube Horizontal Type Large Scale Solar Hot Water Collector Manifold Bracket

1. Solar collector bracket protects and completely encases the solar module.

2. Quality assurance for ten years.

3. Specific customized requirment service available.

4. Frame angle:0, 20,23,25,30,35, 38°, 45°.

5. Beautiful and practical.

6. Installation: tube horizontal type.

1.Suitable for low pressure and high pressure solar hot water collecting system.

2. Materials: Galvanized sheet, Stainless steel or Aluminum alloy.

3. Size: Φ58-1800mm / Φ58-2000mm / Φ70-2100mm

4. Angle: 0°-45°

5. Bearing weight: 720kg

6. Color: As per customer's request.

7. Thickness: 1.0-1.5 mm

8. Surface processing:static blasting painting,baking paint for metal

9. Package:Inner:plastic film or pearl wool outer:shrink film or as clients requests

10. Scope of application: solar water heater home series, solar water heating project series

Free instruction for installation and operation

Please reference the introduction of product and installation manual.

As can be seen by the diagram above, the sun is low in the sky during the winter and high in the summer.

So before enjoy hot water from the sun, consult your local plumber or contractor company to ensure a good installation.

We`d also be happy to recommend our partners in plumbing for your references.

Here I`d like to share you with some more installation site gallery regarding flat roof and tilt roof.
