Home > Products > Home Power Inverter > Home Inverter 10KW,Compatible with generator
Home Inverter 10KW,Compatible with generator
- Foshan/Guangzhou/Shenzhen
- Credit Card
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | Greentechy | |
| Model Number | Soho-C10KW | Output Power | Other, 10KW | |
| Output Type | Other, single phase or three phase | Size | 645*350*730 | |
| Weight | 74 | Input Voltage | 24VDC/48VDC/96VDC or others | |
| Output Voltage | 110/120/220/230VAC | Type | Other, DC/AC Inverters, Pure sine wave home inverter | |
| Output Frequency | 50Hz/60Hz |
Product Description
Specifications
1. Pure sine wave,CPU control.2. Wide input range of 110-280V.
3. Power frequency design.
4. Compatible with generator.
10kw Home inverter/10kw home UPS inverter with charger/10kw solar power inverter
NEW HOME INVERTER, PURE SINE WAVE INVERER, BEST OFFER!!!
Can be with different loads, very wide input range of 110v-280v, double layer PCB board!
Features:
1. Pure sine wave output,home inverter can be used with different house appliance TV,refrigerator,fan,air conditioner,induction cooker,micro-wave over etc.
2. Superior performance from CPU control technology.
3. Protection for over-load,short circuit,over-voltage,low-voltage,over-heating etc.
4. Concise LED display and distinctive LCD display are optional.
5. Which satisfy the power supply for different back up time.
6. Intelligent battery management with protection against over-charged and over-discharged etc.
7. Wide range of input voltage,accurate output,AVR function.
8. Generator compatibly and external battery connection achievable
Technical Specification:
Model Soho-C**** | 122 | 152 | 182 | 202 | 302 | 402 | 502 | 602 | 752 | 103 | |
Rated capacity(W) | 1200W | 1500W | 1800W | 2KW | 3KW | 4KW | 5KW | 6KW | 7500W | 10KW | |
Output | Commercial power range(VAC) | 100/110/120/127/220/ 230(+25%,-35%) | 100/110/120/127/220/ 230±20% | ||||||||
AVR Voltage range(VAC) | 100/110/120/127/220/ 230±10% (Auto-sensing) | (NO) | |||||||||
Transfer time | Typical:5ms(Including detection time) | ||||||||||
Battery | DC Voltage | 24/48VDC | 48/96VDC | 96/192VDC | |||||||
Appearance | Body size(mm) L×W×H | 460×220×385 | 460×260×470 | 550×262×605 | |||||||
Size(mm) L×W×H | 504×272×445 (1 piece) | 555×345×530 (1 piece) | 645×350×730 (1 piece) | ||||||||
Net weight (kg) | 17 | 22.0 | 25.0 | 23.0 | 28.0 | 32.0 | 33.0 | 39.0 | 63.0 | 64.0 | |
Gross weight (kg) | 19.7 | 24.0 | 27.0 | 25.0 | 30.0 | 34.0 | 35.0 | 41.0 | 73.0 | 74.0 | |
Input | Frequency(Hz) | 60/50±10% |
Output | Waveform | Sine wave |
Frequency(Hz) | Commercial power supply :shared frequency with the commercial inversion state:60Hz/50Hz ±0.5 | |
Protection | Overload | IPS automatically shutdown if overload exceeds 120% of normal value for 10 seconds,IPS automatically resume work if overload comes back to rated load. |
Battery | Type | Sealed,maintenance-free lead acid |
Recharge current | 15A(Maximum) | |
Battery protection | Automatic self-test,discharge protection,over-charging protected,smart management system. |
